Bently 3500/05-01-01-00-00-00

Product Introduction
This complete part number represents a 19-inch full-size instrumentation rack frame with all standard options specified. The extended suffix “00-00-00” confirms base-level mechanical options, standard version, and basic functional configuration for the 3500 Machinery Protection System.

Category:

Description

Bently 3500/05-01-01-00-00-00

Technical Specifications

  • Frame Type: 19-inch EIA Standard Rack (Full Size)
  • Module Capacity: 14 available module slots
  • Mounting Option: Panel Mount (Option 01)
  • Frame Type Code: Full Size (Option 01)
  • Version: First Version (Option 00)
  • Special Features: Basic Functionality (Option 00)

Functional Features

  • Complete Specification: All mechanical and electrical options fully defined in part number.
  • Standard Configuration: Base-level frame suitable for most industrial applications.
  • Full Backplane Support: Complete power and communication bus for 14-slot capacity.
  • API 670 Compliant: Meets all mechanical protection system rack requirements.

Application Scenarios
Universal deployment in rotating machinery protection systems across all industrial sectors requiring 3500 monitoring infrastructure.

Performance Parameters

  • Operating Environment: Indoor industrial, -30°C to +65°C
  • Vibration Rating: Continuous industrial vibration exposure
  • EMI Protection: Full backplane and chassis shielding

Material Composition
Industrial-grade steel with protective coating, precision card guides, and gold-plated backplane contacts for reliable connections.

Structural Characteristics
19-inch rack with panel mount clamps, rear I/O access, grounding studs, and integrated cable management. Front-access module slots with ejector mechanisms.

Working Principle
Provides the integrated mechanical, electrical, and communication infrastructure for the 3500 system through the backplane power distribution and data bus.

Installation Requirements
Install in 19-inch panel opening with proper clamping. Connect instrument ground. Maintain ventilation clearance. Install power and interface modules in leftmost slots first.

Usage Precautions
Verify all suffix options match application requirements. Never force modules into slots. Perform backplane continuity test before system energization.
