Description
Bently 3500/05
Technical Specifications
- Frame Type: 19-inch EIA Standard Rack
- Module Capacity: 14 available module slots
- Backplane: Integrated communication and power distribution
- Compliance: 19-inch EIA Standard
Functional Features
- Modular Architecture: Supports hot-swappable modules for maintenance without system shutdown.
- Backplane Communication: Provides high-speed data bus for inter-module communication.
- Power Distribution: Delivers regulated DC power from power supply modules to all installed monitors.
- Grounding System: Integrated single-point grounding for noise immunity.
Application Scenarios
Deployed in power generation, petrochemical, and metallurgical facilities as the central housing for all 3500 machinery protection and condition monitoring modules.
Performance Parameters
- Operating Temperature Range: -30°C to +65°C (-22°F to +149°F)
- Vibration Resistance: Designed for continuous operation in high-vibration industrial environments
- EMI/RFI Shielding: Comprehensive shielding for signal integrity
Material Composition
Constructed from heavy-gauge steel with powder-coated finish for corrosion resistance and mechanical durability.
Structural Characteristics
Standard 19-inch rack form factor with front-access module slots, rear I/O access, and integrated cable management provisions. Includes grounding studs and mounting hardware.
Working Principle
Provides the physical and electrical infrastructure for the 3500 system. The backplane routes power from supply modules to all slots and provides high-speed digital communication between monitor modules and interface modules.
Installation Requirements
Mount securely to a 19-inch EIA rack or panel using provided hardware. Ensure adequate ventilation clearance. Connect instrument ground to the designated grounding stud.
Usage Precautions
Never exceed the maximum module capacity. Ensure proper grounding to prevent noise issues. Keep the backplane connectors clean and free of debris during module installation.
