Description
Bently 3500/22-138607-01
Technical Specifications
- Module Type: Transient Data Interface
- PWA Number: 138607-01
- Data Type: High-speed dynamic waveform and transient captures
- Slot Requirement: Dedicated communication/transient slot
Functional Features
- Exact Hardware Match: Guarantees identical electrical characteristics, firmware compatibility, and physical dimensions as the original module.
- Traceability: Allows maintenance teams to track production dates, firmware revisions, and factory calibration records.
- Standard Transient Functionality: Provides all standard waveform capture and System 1 integration features.
Application Scenarios
Used in spare parts inventory management, precision replacements during system upgrades, and facilities with strict hardware audit requirements.
Performance Parameters
- Operating Temperature: -30°C to +65°C
- Storage Temperature: -40°C to +85°C
- Humidity: 95% non-condensing
- Data Transfer Rate: High-speed proprietary backplane protocol
Material Composition
Manufactured to exact OEM specifications using high-speed digital components and conformal-coated PCBs.
Structural Characteristics
Identical physical footprint to standard 3500/22 modules. The PWA number is typically silk-screened on the internal circuit board for verification.
Working Principle
Functions identically to the standard 3500/22 module, capturing and transmitting high-speed transient data via the rack backplane.
Installation Requirements
Install in the designated transient data slot. Verify the PWA number matches the system documentation before installation.
Usage Notes
When replacing a module, always verify that the PWA revision is compatible with the current system firmware version. Consult Bently Nevada documentation if upgrading from an older PWA revision.
