Description
Bently 3500 22M3500 22-01-01-00
Technical Specifications
- Module Type: Enhanced TDI (M-Series)
- Configuration: 01-01-00 (Standard)
- Network Interface: 10/100 Base-TX Ethernet
- Slot Requirement: Slot 1
Functional Features
- Enhanced Processing: Faster data buffering and transmission rates for high-channel-count racks.
- Advanced Diagnostics: Provides more detailed internal health monitoring and network troubleshooting data.
- Backward Compatibility: Fully supports existing 3500 M-series monitors and System 1 software.
Application Scenarios
Ideal for modernizing existing 3500 systems, new installations with high data throughput requirements, and facilities utilizing advanced predictive maintenance analytics.
Performance Parameters
- Operating Temperature: -30°C to +65°C
- Storage Temperature: -40°C to +85°C
- Humidity: 95% non-condensing
- Data Update Rate: < 1 second
Material Composition
Next-generation microprocessors and high-speed memory components with enhanced thermal management.
Structural Characteristics
Standard TDI physical footprint with updated front-panel LED logic for enhanced status visibility.
Working Principle
Utilizes upgraded firmware and hardware to efficiently aggregate and transmit both steady-state and transient data over the Ethernet link.
Installation Requirements
Installed in Slot 1. Ensure the 3500 Rack Configuration Software version supports the 22M module.
Usage Notes
When replacing a legacy 3500/22 with a 22M, verify that the system firmware is updated to recognize the enhanced module.
