Description
Bently 3500 25-01-03
Technical Specifications
- Module Type: Keyphasor Module
- Configuration: 01-03 (Variant)
- Channels: Dual-channel design
- Slot Requirement: Any available monitor slot
Functional Features
- Specialized Processing: Tailored signal conditioning for specific application requirements.
- Backward Compatibility: Designed to integrate seamlessly with older 3500 systems or specific plant configurations.
- Standard Keyphasor Functions: Retains core speed and phase detection capabilities.
Application Scenarios
Used in system upgrades, legacy replacements, or specialized machinery where standard Keyphasor configurations do not meet specific operational needs.
Performance Parameters
- Operating Temperature: -30°C to +65°C
- Storage Temperature: -40°C to +85°C
- Humidity: 95% non-condensing
Material Composition
OEM-specification industrial electronics.
Structural Characteristics
Full-height module with standard LED indicators.
Working Principle
Processes sensor inputs according to the variant-specific firmware to generate speed and phase signals.
Installation Requirements
Install in an available monitor slot. Verify configuration matches the original system design.
Usage Notes
Always verify the complete ordering code, including the “-03” variant, to ensure compatibility with the existing system.
