Description
Bently 3500 25-02-01-00
Technical Specifications
- Module Type: Dual-Channel Keyphasor Module
- Configuration: 02-01-00
- Active Channels: 2
- Slot Requirement: Any available monitor slot
Functional Features
- Space Efficiency: Provides two independent Keyphasor signals in a single module slot.
- Independent Configuration: Each channel can be configured for different sensor types and trigger levels.
- Dual Synchronization: Distributes two separate phase reference signals to the rack.
Application Scenarios
Ideal for gearboxes, multi-shaft machines, or densely packed monitoring racks where slot conservation is critical.
Performance Parameters
- Operating Temperature: -30°C to +65°C
- Storage Temperature: -40°C to +85°C
- Humidity: 95% non-condensing
Material Composition
High-density industrial electronics.
Structural Characteristics
Full-height module with dual-channel status indicators.
Working Principle
Independently processes two sensor inputs and generates two synchronized Keyphasor signals.
Installation Requirements
Install in an available monitor slot. Connect two separate sensor cables.
Usage Notes
Configure each channel independently in the 3500 Rack Configuration Software. Verify both channels are functioning correctly after installation.
