Description
Bently 3500/42M-09-00
Technical Specifications
- Module Type: Displacement/Velocity Monitor
- Configuration Code: 09-00 (Displacement/Velocity, Internal Terminations)
- Channel Count: 4 independent channels
- Slot Placement: Any available monitor slot
Functional Features
- Dual-Parameter Measurement: Specifically configured to process both proximity probe (displacement) and velocity sensor inputs.
- Internal Terminations: Provides secure, integrated wiring connections.
- Flexible Channel Pairing: Channels can be paired to execute specific combined monitoring functions.
Application Scenarios
Used in specialized machinery where both axial displacement and velocity vibration must be monitored simultaneously.
Performance Parameters
- Operating Temperature: -30°C to +65°C
- Storage Temperature: -40°C to +85°C
- Humidity: 95% non-condensing
Material Composition
Industrial-grade electronic components with environmental protection coatings.
Structural Characteristics
Full-height module with front-panel connectors and status LEDs.
Working Principle
Processes combined displacement and velocity signals to generate dual-parameter measurements and trigger alarms.
Installation Requirements
Install in an available monitor slot. Connect both proximity and velocity sensor cables.
Usage Notes
Verify the complete ordering code, including the “-09” variant, to ensure compatibility with the existing system.
