Bently 3500/94
Technical Specifications
- Module Type: VGA Display Module
- Display Type: Color VGA Graphical Display
- Slot Placement: Any available monitor slot
- Communication: Backplane integration with 3500 rack
Functional Features
- Graphical Interface: Displays color-coded system overviews, real-time trends, and detailed channel information.
- Advanced Navigation: Intuitive menu system for configuring local display parameters and acknowledging alarms.
- Remote Capability: Supports remote VGA display mounting for centralized control room visibility.
Application Scenarios
Deployed in large control centers where operators require comprehensive graphical visualization of multiple machinery parameters without switching to a dedicated workstation.
Performance Parameters
- Operating Temperature Range: -30°C to +65°C
- Storage Temperature Range: -40°C to +85°C
- Humidity Tolerance: 95% non-condensing
Material Composition
Industrial-grade color LCD panel with ruggedized front-panel controls and high-reliability internal electronics.
Structural Characteristics
Full-height module featuring a color VGA screen, navigation keypad, and front-panel connectors for remote display extension.
Working Principle
Renders graphical data retrieved from the 3500 rack backplane onto the VGA screen, providing real-time visual analytics.
Installation Requirements
Install in any available monitor slot. Ensure proper clearance for the display screen and front-panel access.
Usage Notes
Requires 3500 Rack Configuration Software for initial display layout configuration. Ensure the system firmware supports the 3500/94 module.
