Description
Bently 9200-01-05-10-00
Technical Specifications
- Sensor Type: Two-Wire Velocity Seismic Sensor
- Part Number: 9200-01-05-10-00
- Certification: 05 (Multiple Agency Approvals)
- Cable Length: 10 feet (approx. 3 meters)
Functional Features
- Excellent Corrosion Resistance: Rugged construction requires no additional protective housing for most industrial environments.
- Direct Velocity Output: Eliminates the need for external integration when velocity is the desired measurement parameter.
- Versatile Connectivity: Compatible with 3500 monitors and 9513 Velocity-Displacement Converters.
Application Scenarios
Used extensively for casing vibration monitoring on centrifugal pumps, fans, blowers, and motors in petrochemical and power generation facilities.
Performance Parameters
- Sensitivity: 20 mV/mm/s (500 mV/in/s) ±5% at 100 Hz
- Frequency Range: Standard operating range up to 1 kHz
- Operating Temperature: -29°C to +121°C
Material Composition
Stainless steel or hardened steel casing, corrosion-resistant internal components, and shielded twisted-pair cabling.
Structural Characteristics
Compact cylindrical body with a standard mounting thread and an integrated flexible cable.
Working Principle
Operates on the principle of a moving coil suspended by springs within a permanent magnetic field. Structural vibration causes the coil to move relative to the magnet, inducing a proportional AC voltage.
Installation Requirements
Mount securely using a 3/8-24 UNF or M10 stud. Ensure the cable is routed away from sharp edges and high-temperature surfaces.
Usage Precautions
Do not splice or extend the integrated cable. If excess cable is present, coil it in a diameter no less than 50 mm and secure it to prevent microphonic noise.
