Description
Bently Nevada 330100-045-00-00
Technical Specifications
- Model: 330100-045-00-00
- Series: 3300 Proximity Transducer System
- Cable Length: 4.5 meters
- Cable Type: Standard extension cable
- Connector Option: Standard
- Agency Approval: 00
- Capacitance: 69.9 pF/m typical
- Operating Temperature: -52°C to +177°C
- Connector Material: Gold-plated brass or gold-plated beryllium copper
- Cable Shielding: Triaxial construction with shielding
Function Features
- Reliable signal transmission between probe and Proximitor sensor
- Maintains signal integrity over the 4.5-meter length
- Compatible with 3300 series 5mm and 8mm proximity probes
- Backward-compatible with non-XL 3300 series components
- Gold-plated connectors ensure corrosion resistance and stable electrical contact
- Shielded construction minimizes electromagnetic interference
Application Scenarios
- Vibration and position measurement systems on fluid-film bearing machines
- Shaft displacement monitoring in turbines and compressors
- Keyphasor reference and speed measurement applications
- Rotating machinery condition monitoring in power plants and refineries
Performance Parameters
- Signal attenuation is minimal over full cable length
- Impedance matching is optimized for 3300 series transducer systems
- Pull strength is robust for cable attachment
- Flexibility is suitable for industrial cable routing
Material Composition
- Cable jacket is Fluorinated Ethylene Propylene (FEP) insulation
- Conductors are copper with precision impedance control
- Connectors are gold-plated brass or beryllium copper
- Shielding is braided shield for EMI/RFI protection
Structural Characteristics
- Triaxial cable construction
- Standard diameter for easy routing through conduit
- Finger-tight connectors for field installation
- Color-coded or marked for proper identification
Installation Requirements
- Ensure total system length matches Proximitor sensor calibration
- Route cable away from high-voltage power cables
- Maintain minimum bend radius of 25.4 mm
- Secure cable to prevent strain on connectors
- Verify proper connection at both probe and sensor ends
Operating Considerations
- Do not exceed maximum system length for the Proximitor sensor
- Inspect connectors periodically for corrosion or contamination
- Replace cable if jacket damage exposes internal conductors
- Ensure proper mating of connectors
- Avoid sharp bends or kinks during installation
