Description
Bently Nevada 330101-00-12-05-02-00
Technical Specifications:
- Product Series: 3300 XL 8mm Eddy Current Sensor System
- Probe Diameter: 8mm
- Thread Specification: 3/8-24 UNF Imperial Thread
- Unthreaded Length: 00 = 0.0 inches
- Overall Case Length: 12 = 1.2 inches
- Total Cable Length: 05 = 0.5 meters
- Connector Type: 02 = Miniature coaxial ClickLoc connector, standard cable
- Agency Approval: 00 = Not required
- Weight: Approximately 0.323 kg
Functional Features:
- Short housing design suitable for space-constrained installations
- Non-contact high-precision displacement and vibration measurement
- Fully compatible with 3300 XL series proximitor modules and extension cables
- Complies with API 670 standard requirements for mechanical configuration, linear range, accuracy, and temperature stability
- Components are fully interchangeable without individual matching
Application Scenarios:
- Bearing housing vibration monitoring in space-constrained locations
- Small steam turbine and gas turbine shaft vibration measurement
- Compressor and pump shaft position monitoring
- Keyphasor signal acquisition
Performance Parameters:
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Linear Range: 2mm (80 mils)
- Frequency Response: 0 to 10 kHz
- Supply Voltage: -17.5 VDC to -26 VDC
- Operating Temperature (Probe): -52°C to +177°C (standard type)
Material Composition:
- Probe Tip: PPS Polyphenylene Sulfide
- Probe Housing: Stainless steel
- Cable: Standard coaxial cable
Structural Features:
- Compact short housing design with reduced overall length
- 3/8-24 UNF imperial thread mounting
- 0.5-meter integrated cable with ClickLoc miniature coaxial connector at the end
- Non-armored structure
Working Principle: Based on the eddy current effect, the probe coil generates a high-frequency alternating magnetic field. When a conductive target surface enters the magnetic field range, eddy currents are induced. The reverse magnetic field from these eddy currents alters the coil impedance, and the proximitor converts this impedance change into a voltage signal proportional to the gap distance.
Installation Requirements:
- The total system length (probe cable + extension cable) must match the proximitor’s nominal length
- Mount on a rigid bracket ensuring the probe axis is perpendicular to the target surface
- Set gap voltage to -10.0 VDC ± 0.2V
- Target surface roughness must be better than 1.6μm
Usage Precautions:
- Confirm probe system length matches the proximitor
- Gently rotate the connector by hand until 3 to 4 clicks are heard; do not overtighten
- Cable bending radius must meet minimum requirements; right-angle bends are prohibited
- Shield must be grounded at a single point only
