Description
Bently Nevada 330103-00-16-05-02-00
Technical Specifications:
- Probe Diameter: 8 mm
- Mounting Thread: M10×1 metric thread
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Linear Range: 2 mm (0.25 mm to 2.3 mm)
- Frequency Response: 0 to 10 kHz
- Recommended Gap Setting: 1.27 mm (50 mils), approximately -10 Vdc
- Operating Temperature (Probe Tip): -51°C to +177°C
- Connector Type: ClickLoc miniature coaxial connector (code 02)
- Agency Approvals: None (standard industrial, -00 suffix)
- Compliance: API 670 standard
Functional Features:
- Non-contact eddy current measurement with sub-micron resolution
- Multi-parameter monitoring: vibration, displacement, keyphasor, speed, eccentricity
- ClickLoc connector for secure, IP67-rated connection
- Interchangeable within the 3300 XL 8mm system
- Compatible with 3500, 2300/20, and 1900/65A monitoring platforms
Application Scenarios:
- Steam turbines and generators
- Centrifugal compressors and pumps
- Fans, blowers, and gearboxes
- Electric motors and large rotating equipment
- General industrial machinery condition monitoring
Performance Parameters:
- Sensitivity: 7.87 V/mm ±5% (5m system)
- Linearity: ±1% full scale
- Resolution: 0.1 μm
- Frequency Response: DC to 10 kHz
