Bently Nevada 330130-030-00-05
Technical Specifications
- Model: 330130-030-00-05
- Series: 3300 XL Proximity Transducer System
- Cable Length: 3.0 meters (9.8 feet)
- Connector Protector and Cable Option: 00 (standard cable)
- Agency Approval: 05 (CSA, ATEX, IECEx multiple approvals)
- Capacitance: 69.9 pF/m (21.3 pF/ft) typical
- Operating Temperature: -52°C to +177°C (-62°F to +350°F)
- Extended Temperature Range Option: -52°C to +260°C
- Connector Material: Gold-plated brass or gold-plated beryllium copper
- Weight: 34 g/m (0.4 oz/ft)
Function Features
- Reliable signal transmission for critical machinery monitoring
- Complete interchangeability of probes, extension cables, and Proximitor sensors
- Backward compatibility with non-XL 3300 series 5mm and 8mm components
- Multiple agency approvals for hazardous area installations
- Durable construction for harsh industrial environments
- No need for individual component matching or bench calibration
Application Scenarios
- Vibration and position measurements on fluid-film bearing machines
- Keyphasor reference and speed measurement applications
- Compression system monitoring
- Steam turbine and gas turbine protection
- Centrifugal and axial compressor monitoring
Performance Parameters
- Extension cable capacitance is 69.9 pF/m typical
- System linear range is 2.0 mm (80 mils)
- Scale factor is 7.87 V/mm (200 mV/mil)
- Frequency response is 0 Hz to 10 kHz
- Power supply sensitivity is less than 2 mV change per volt change in input voltage
Material Composition
- Cable jacket is Fluorinated Ethylene Propylene (FEP)
- Conductors are copper
- Connectors are gold-plated brass or beryllium copper
- Shielding is triaxial shielded construction
Structural Characteristics
- Standard non-armored cable construction
- Triaxial design for signal integrity
- Gold-plated ClickLoc connectors at both ends
- Gray or blue cable jacket
- Compact dimensions
Installation Requirements
- Verify total cable length matches Proximitor sensor system calibration
- Install with minimum bend radius of 25.4 mm
- Route away from high-voltage power conductors
- Secure cable to prevent mechanical strain on connections
- Ensure proper engagement of ClickLoc connectors
Operating Considerations
- Suitable for hazardous areas with CSA, ATEX, and IECEx approvals
- Maximum field wiring length between Proximitor sensor and monitor is 305 meters
- Inspect cable condition during routine maintenance
- Replace if insulation damage is detected
- Maintain connector cleanliness for optimal signal transmission
