Description
Bently Nevada 330130-032-00-00
Technical Specifications
- Model: 330130-032-00-00
- Series: 3300 XL Proximity Transducer System
- Cable Length: 3.2 meters
- Connector Protector and Cable Option: 00 (standard cable)
- Agency Approval: 00
- Capacitance: 69.9 pF/m (21.3 pF/ft) typical
- Operating Temperature: -52°C to +177°C (-62°F to +350°F)
- Connector Material: Gold-plated brass or gold-plated beryllium copper
- Weight: 34 g/m (0.4 oz/ft)
Function Features
- Extended 3.2-meter length for specific installation requirements
- Reliable signal transmission for vibration and position monitoring
- Complete component interchangeability within 3300 XL system
- Backward compatibility with non-XL 3300 series transducers
- Gold-plated connectors for stable electrical contact
- Standard cable construction for general industrial use
Application Scenarios
- Fluid-film bearing machine monitoring
- Rotating shaft vibration measurement
- Axial position monitoring systems
- Keyphasor reference signal routing
- Machinery protection in power generation and petrochemical industries
Performance Parameters
- Extension cable capacitance is 69.9 pF/m typical
- System accuracy is maintained over full cable length
- Impedance is matched to 3300 XL transducer requirements
- Signal fidelity preserves dynamic and static signals
- Temperature stability provides consistent performance across range
Material Composition
- Cable jacket is Fluorinated Ethylene Propylene (FEP)
- Conductors are copper with precision impedance characteristics
- Connectors are gold-plated brass or beryllium copper
- Shielding is triaxial braided shield
Structural Characteristics
- Standard non-armored flexible cable
- Triaxial design for EMI/RFI immunity
- ClickLoc gold-plated connectors
- 3.2 meter length for specific routing requirements
- Compact and lightweight construction
Installation Requirements
- Ensure combined probe and cable length matches Proximitor calibration
- Install with minimum 25.4 mm bend radius
- Secure cable along routing path to prevent strain
- Separate from high-voltage cables to prevent interference
- Verify proper ClickLoc connector engagement
Operating Considerations
- Verify system length compatibility with Proximitor sensor
- Inspect cable jacket integrity during maintenance
- Replace if conductors become exposed
- Keep connectors clean and dry
- Avoid sharp bends or crushing forces on cable
