Description
Bently Nevada 330130-80-01-00
Technical Specifications
- Model: 330130-80-01-00 (equivalent to 330130-080-01-00)
- Series: 3300 XL Proximity Transducer System
- Cable Length: 8.0 meters (26.2 feet)
- Connector Protector and Cable Option: 01 — Armored cable
- Agency Approval: 00 — Not required
- Cable Construction: 75 Ω triaxial, Fluorinated Ethylene Propylene (FEP) insulated with armor
- Capacitance: 69.9 pF/m (21.3 pF/ft) typical
- Operating Temperature: -51°C to +177°C (-60°F to +350°F)
- Weight: Approximately 0.89 kg
- Connector Type: Gold-plated ClickLoc miniature coaxial connectors
Function Features
- Armored construction provides enhanced mechanical protection
- Gold-plated ClickLoc connectors for corrosion resistance
- Complete interchangeability with 3300 XL system components
- Backward compatibility with non-XL 3300 series transducers
- Maintains full system accuracy and linearity
- CableLoc design provides 330 N (75 lbf) pull strength
Application Scenarios
- Machinery monitoring in physically demanding environments
- Steam and gas turbine protection systems
- Centrifugal compressor condition monitoring
- Keyphasor and speed measurement systems
- Industrial rotating machinery vibration monitoring
Performance Parameters
- Extension cable capacitance is 69.9 pF/m typical
- System linear range is 2.0 mm (80 mils)
- Scale factor is 7.87 V/mm (200 mV/mil)
- Frequency response is 0 Hz to 10 kHz
- Supply sensitivity is less than 2 mV per volt change
Material Composition
- Cable jacket is Fluorinated Ethylene Propylene (FEP)
- Armor is flexible AISI 302 stainless steel with FEP outer jacket
- Conductors are copper with precision impedance control
- Connectors are gold-plated brass or beryllium copper
Structural Characteristics
- Armored construction for enhanced mechanical protection
- Triaxial cable design
- ClickLoc connectors at both ends
- Flexible armor for routing in industrial environments
- Robust construction for crush and abrasion resistance
Installation Requirements
- Ensure total system length matches Proximitor sensor calibration
- Route cable with minimum 25.4 mm bend radius
- Secure cable to prevent strain on connectors
- Maintain separation from high-voltage cables
- Verify ClickLoc connectors are fully engaged
Operating Considerations
- Do not exceed maximum system length for matched Proximitor sensor
- Inspect armor for damage during maintenance rounds
- Verify connector tightness periodically
- Replace if cable jacket or armor shows excessive wear
- Ensure proper mating of gold-plated connectors
