Description
Bently Nevada 330705-02-18-10-02-00
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 330705-02-18-10-02-00 |
| Mount Type | Reverse mount |
| Thread Type | 3/8-24 UNF |
| Unthreaded Length | 0.2 inch |
| Overall Case Length | 1.8 inch |
| Total Cable Length | 1.0 meter (3.3 feet) |
| Connector Type | Miniature coaxial ClickLoc connector, standard cable |
| Agency Approval | Not required |
| Probe Tip Diameter | 11 mm |
| Sensitivity | 3.94 V/mm (100 mV/mil) ±10% |
| Linear Range | 4.0 mm (160 mils) |
| Frequency Response | 0 to 8 kHz |
| Output Resistance | 50 Ω |
| Temperature Range | -52°C to +177°C (-62°F to +351°F) |
| Weight | 70 g (2.5 oz) |
Functional Features The reverse mount configuration is ideal for applications with counter bore, sideview, or rearview restrictions. The probe features the patented TipLoc molding method for robust tip-to-body bonding and CableLoc design for 330 N (75 lbf) pull strength. The gold-plated brass ClickLoc connector ensures secure, vibration-resistant connections. Reverse mount probes are not available with armor, FluidLoc cable, or connector protector options.
Application Scenarios Small turbine gear movement monitoring in tight spots, laboratory machine testing equipment, food processing equipment monitoring, confined space installations where standard forward mount probes cannot fit, axial position measurement in restricted access areas, reciprocating compressor rod drop monitoring in compact housings.
Performance Parameters The probe delivers 3.94 V/mm (100 mV/mil) nominal sensitivity with a linear measurement range of 4.0 mm. The system maintains accuracy within ±0.10 mm deviation from best fit straight line over the standard linear range. The DC resistance for the 1.0 meter probe length is 5.9 ± 0.5 Ω from center conductor to outer conductor.
Material Composition Probe tip is polyphenylene sulfide (PPS). Probe case is AISI 304 stainless steel. Cable is 75 Ω triaxial with FEP insulation. The pressure seal consists of a Viton O-ring.
Structural Characteristics The reverse mount probe features 3/8-24 UNF-2A threads. The case length of 1.8 inches provides adequate mounting depth while maintaining a compact profile for tight spaces. The unthreaded length of 0.2 inch positions the thread appropriately for internal mounting. The probe body is designed without armor options due to the reverse mount configuration.
