Description
Bently Nevada 330801-16-04-050-00-02
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 330801-16-04-050-00-02 |
| Thread Type | 3/8-24 UNF |
| Armor Option | Without armor |
| Unthreaded Length | 0.4 inch |
| Overall Case Length | 1.6 inch |
| Total Cable Length | 5.0 meters (16.4 feet) |
| Connector Type | Miniature coaxial ClickLoc connector, standard cable |
| Agency Approval | Not required |
| Probe Tip Diameter | 8 mm |
| Sensitivity | 7.87 V/mm (200 mV/mil) ±10% |
| Linear Range | 2.0 mm (80 mils) |
| Frequency Response | 0 to 8 kHz |
| Output Resistance | 50 Ω |
| Power Requirements | -17.5 Vdc to -26 Vdc |
| Recommended Gap | 1.27 mm (50 mils) |
Functional Features The probe features complete interchangeability with other 3300 XL 8 mm system components without matching or calibration. The gold-plated brass ClickLoc connector locks into place, preventing loosening under vibration. The probe comes standard with a locknut with pre-drilled safety wire holes. The 3/8-24 UNF thread is supplied with a 9/16 inch lock nut and 5/16 inch wrench flats.
Application Scenarios Radial vibration monitoring on turbines, compressors, pumps, and motors, axial thrust position measurements, tachometer and zero speed measurements, phase reference Keyphasor signals, rod position and rod drop measurements on reciprocating compressors, general industrial machinery condition monitoring.
Performance Parameters The Incremental Scale Factor is 7.87 V/mm (200 mV/mil) ±10% including interchangeability error when measured in increments of 0.25 mm over the 2.0 mm linear range. Deviation from best fit straight line is less than ±0.025 mm. Over a probe temperature range of -35°C to +120°C with the Proximitor Sensor and extension cable between 0°C to +45°C, the ISF remains within ±10% of 7.87 V/mm.
Material Composition Probe tip is polyphenylene sulfide (PPS). Probe case is AISI 304 stainless steel. The cable is 75 Ω triaxial with fluoroethylene propylene (FEP) insulation. Connector material is gold-plated brass.
