Bently Nevada 330901-00-40-05-02-05

Bently Nevada 330901-00-40-05-02-05

Product Overview The 330901-00-40-05-02-05 is an extended standard mount proximity probe from the 3300 NSv family. It features a 4.0 inch overall case length with 1/4-28 UNF imperial thread and 0.5 meter integral cable. The extended case length provides substantial threaded engagement for deep mounting applications or installations through thick adapter plates. Multiple agency approvals ensure compliance with international hazardous area requirements.

Request Quote
Category:

Description

Bently Nevada 330901-00-40-05-02-05

Technical Specifications

  • Base Model: 330901, 3300 NSv Probe with 1/4-28 UNF thread, without armor
  • Unthreaded Length: 0.0 inches (fully threaded)
  • Overall Case Length: 4.0 inches (101.6 mm)
  • Total Probe Length: 0.5 meter (20 inches)
  • Connector Type: Miniature coaxial ClickLoc connector, standard cable
  • Agency Approval: Multiple approvals
  • Linear Range: 1.5 mm (60 mils)
  • Scale Factor: 7.87 V/mm (200 mV/mil)
  • Frequency Response: 0 to 10 kHz
  • Probe Tip Diameter: 5 mm
  • Probe Case Material: AISI 304 stainless steel
  • Probe Tip Material: Polyphenylene sulfide
  • Operating Temperature: -52°C to +177°C
  • Storage Temperature: -52°C to +177°C
  • DC Resistance: 4.0 ± 0.5 Ω
  • Minimum Bend Radius: 25.4 mm

Functional Features

  • Extended 4.0 inch case for deep mounting requirements
  • 1/4-28 UNF thread for North American equipment
  • Multiple hazardous area certifications
  • Short 0.5 meter cable for close-coupled installations
  • ClickLoc connector with positive locking
  • Compatible with full 3300 XL NSv system
  • Interchangeable without recalibration

Application Scenarios

  • Deep bearing housing penetrations
  • Thick-wall compressor casing monitoring
  • Large pump and turbine applications
  • North American petrochemical equipment
  • Hazardous area rotating machinery

Performance Parameters

  • Linearity Deviation: Less than ±0.06 mm
  • Resolution: Sub-micron detection capability
  • Temperature Stability: ±10% over full range
  • Interchangeability: Within system specifications
  • Maximum Thread Engagement: 0.375 inches
  • Recommended Torque: 5.1 N·m

Material Composition

  • Probe Case: AISI 304 stainless steel
  • Probe Tip: Polyphenylene sulfide
  • Cable Insulation: Fluorinated ethylene propylene
  • Connector Contacts: Gold-plated brass

Structural Characteristics

  • Long 4.0 inch cylindrical threaded body
  • 0.5 meter integral coaxial cable
  • Miniature ClickLoc connector
  • PPS probe tip with TipLoc bonding
  • Robust construction for industrial environments

Working Principle The probe generates a high-frequency electromagnetic field through its internal coil. Eddy currents induced in the conductive target surface modify the coil impedance in proportion to gap distance. The Proximitor sensor converts this impedance change into a linear voltage output providing both DC position and AC vibration data.

Installation Requirements

  • Install in 1/4-28 UNF threaded hole with adequate depth
  • Ensure perpendicular alignment to target
  • Set gap to 1.0 mm
  • Verify -10 Vdc gap voltage
  • Maintain minimum cable bend radius
  • Use compatible NSv extension cables if needed

Usage Precautions

  • Verify mounting hole depth accommodates 4.0 inch case
  • Do not overtighten during installation
  • Inspect probe tip for damage
  • Ensure connector is fully locked
  • Short cable requires nearby Proximitor mounting
  • Handle extended case carefully to prevent bending
