Description
Bently Nevada 330903-03-19-10-02-00
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 330903-03-19-10-02-00 |
| Thread Type | M8 x 1 |
| Armor Option | Without armor |
| Unthreaded Length | 0.3 inch |
| Overall Case Length | 1.9 inch |
| Total Cable Length | 1.0 meter (3.3 feet) |
| Connector Type | Miniature coaxial ClickLoc connector, standard cable |
| Agency Approval | Not required |
| Probe Tip Diameter | 5 mm (0.20 in) |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Linear Range | 1.5 mm (60 mils) |
| Frequency Response | 0 to 10 kHz |
| Operating Temperature | -35°C to +177°C (-31°F to +350°F) |
Functional Features The NSv probe features enhanced side-view characteristics allowing installation in confined spaces. The 5 mm tip diameter enables measurement on small targets such as shafts smaller than 51 mm. The M8 x 1 metric thread provides compact mounting in small housings. The probe has increased chemical resistance compared to previous RAM probes. The ClickLoc connector ensures secure connection under vibration.
Application Scenarios Small centrifugal compressor monitoring, refrigeration equipment vibration measurement, compact process gas compressor installations, small pump shaft monitoring, electric motor bearing monitoring, gearboxes with limited mounting space, OEM equipment with tight probe clearance.
Performance Parameters The probe delivers 7.87 V/mm sensitivity with linearity within system specifications over the 1.5 mm range. The 1.9 inch case provides adequate thread engagement for secure mounting. The 0.3 inch unthreaded length positions the sensing element correctly. The system maintains full interchangeability without recalibration.
Material Composition Probe tip is polyphenylene sulfide (PPS). Probe case is AISI 304 stainless steel. Cable is 75 Ω triaxial with FEP insulation. Connector material is gold-plated brass.
Structural Characteristics The probe features M8 x 1 metric thread with a compact 1.9 inch case length. The 0.3 inch unthreaded length positions the thread appropriately for the mounting surface. The non-armored cable has a 3.68 mm maximum outside diameter. The probe comes with a locknut containing pre-drilled safety wire holes.
Working Principle The probe generates a high-frequency electromagnetic field at the 5 mm probe tip. Eddy currents induced in the conductive target surface modify the RF field characteristics. The Proximitor Sensor measures these modifications and outputs a DC voltage proportional to the gap distance.
