Product Overview The 330905-00-12-10-02-05 is a compact standard mount proximity probe from the 3300 NSv transducer family. It features an M10×1 metric thread with a 120 mm overall case length and 1.0 meter integral cable. The shorter case length compared to the 150 mm variant makes it suitable for installations with limited depth or confined mounting spaces while maintaining the full NSv performance characteristics for small-target vibration and position measurement.

Request Quote
Category:

Description

Bently Nevada 330905-00-12-10-02-05

Technical Specifications

  • Base Model: 330905, 3300 NSv Probe with M10×1 thread, without armor
  • Unthreaded Length: 0 mm (fully threaded)
  • Overall Case Length: 120 mm
  • Total Probe Length: 1.0 meter (39 inches)
  • Connector Type: Miniature coaxial ClickLoc connector, standard cable
  • Agency Approval: Multiple approvals
  • Linear Range: 1.5 mm (60 mils)
  • Scale Factor: 7.87 V/mm (200 mV/mil)
  • Frequency Response: 0 to 10 kHz
  • Probe Tip Diameter: 5 mm
  • Probe Case Material: AISI 304 stainless steel
  • Probe Tip Material: Polyphenylene sulfide
  • Operating Temperature: -52°C to +177°C
  • Storage Temperature: -52°C to +177°C
  • DC Resistance: 4.2 ± 0.5 Ω
  • Minimum Bend Radius: 25.4 mm

Functional Features

  • Compact 120 mm case for restricted mounting depths
  • Narrow Side-view magnetic field geometry for tight clearances
  • Optimized for shafts smaller than 51 mm and flat targets under 15 mm
  • Compatible with full 3300 XL NSv transducer system
  • ClickLoc connector prevents loosening under vibration
  • System components interchangeable without recalibration
  • Superior chemical resistance for process compressor applications

Application Scenarios

  • Compact bearing housings with shallow mounting depths
  • Gearbox vibration monitoring in confined spaces
  • Small centrifugal pump shaft position tracking
  • Industrial fan bearing condition assessment
  • OEM equipment with space-optimized designs

Performance Parameters

  • Linearity Deviation: Less than ±0.06 mm
  • Resolution: Sub-micron displacement detection
  • Interchangeability: Within system tolerance when matched with NSv Proximitor
  • Temperature Drift: Less than ±10% sensitivity variation over operating range
  • Maximum Thread Engagement: 15 mm
  • Recommended Torque: 11.3 N·m

Material Composition

  • Probe Case: AISI 304 stainless steel
  • Probe Tip: Polyphenylene sulfide
  • Cable Insulation: Fluorinated ethylene propylene
  • Connector Contacts: Gold-plated brass
  • O-ring Seal: Fluorocarbon elastomer

Structural Characteristics

  • Cylindrical 120 mm threaded body
  • Integral 1.0 meter FEP-insulated coaxial cable
  • Miniature ClickLoc coaxial connector
  • PPS probe tip bonded with TipLoc molding process
  • Compact packaging for high-density machinery installations

Working Principle The probe operates on eddy-current sensing principles. An internal coil generates a high-frequency electromagnetic field at the probe tip. When a conductive target approaches, induced eddy currents modify the coil impedance. The associated Proximitor sensor converts this impedance change into a DC voltage proportional to gap distance, with AC components representing dynamic vibration.

Installation Requirements

  • Install in M10×1 threaded mounting hole
  • Ensure perpendicular alignment to target surface
  • Set gap to 1.0 mm for center of linear range
  • Verify -10 Vdc gap voltage at installation
  • Maintain 25.4 mm minimum cable bend radius
  • Use NSv-specific extension cables and Proximitor sensors

Usage Precautions

  • Do not force probe into undersized holes
  • Avoid mechanical impact to probe tip
  • Verify connector is fully locked after mating
  • Do not mix with non-NSv system components
  • Check thread condition before each installation
  • Store in original packaging to prevent connector damage
