Bently Nevada 330930-040-01-001

Bently Nevada 330930-040-01-001

  • Product Overview: The 330930-040-01-001 is a variant of the 4.0-meter armored NSv extension cable. The additional trailing digit “1” in the final suffix position typically denotes a specific modification, agency certification, or regional documentation variant applied to the base 330930-040-01-00 configuration. This part number represents a factory-configured version with specific compliance or documentation requirements.
Request Quote
Category:

Description

Bently Nevada 330930-040-01-001

  • Technical Specifications:
    • Cable Length: 4.0 meters (13.1 feet)
    • Cable Type: Low-noise coaxial with stainless steel armor
    • Connector Type: ClickLoc miniature coaxial connectors
    • Capacitance: 69.9 pF/m (21.3 pF/ft) typical
    • Operating Temperature: -51°C to +177°C (-60°F to +351°F)
    • Compatibility: 3300 XL NSv proximity probes and 330980 NSv Proximitor sensors
    • Certification: Modified or certified variant (suffix “-001” indicates specific compliance configuration)
  • Functional Features:
    • Stainless steel armor for mechanical protection
    • ClickLoc locking connectors for vibration-resistant connections
    • Low-noise coaxial signal transmission
    • Full interchangeability within the 3300 XL NSv system
    • Specific certification or modification as indicated by the trailing suffix
  • Application Scenarios:
    • Hazardous area installations requiring specific agency certifications
    • Oil and gas processing facilities with stringent compliance requirements
    • Chemical plant rotating equipment
    • Power generation auxiliary machinery
  • Performance Parameters:
    • System sensitivity: 7.87 mV/μm (200 mV/mil) ± 6.5%
    • Linear range: 0.5 to 1.75 mm (20 to 55 mil)
    • Frequency response: 0 to 10 kHz
    • Signal attenuation at 1 kHz: less than 1%
    • Signal attenuation at 10 kHz: less than 5%
  • Material Composition:
    • Low-noise coaxial cable with stainless steel braided armor
    • ClickLoc miniature coaxial connectors with gold-plated contacts
    • Industrial-grade outer jacket
  • Structural Features:
    • Stainless steel armored construction
    • Factory-terminated connectors
    • Certification markings or documentation as specified by the trailing suffix
  • Working Principle:
    • The cable carries the high-frequency eddy current excitation signal from the Proximitor to the NSv probe and returns the gap-proportional modulated signal. The electrical characteristics are identical to the base 330930-040-01-00 model; the trailing suffix indicates administrative or compliance differences rather than fundamental electrical changes.
  • Installation Requirements:
    • Route armored cable through conduit or cable tray
    • Maintain minimum bending radius of 45 mm
    • Ground the armor shield at one end only
    • Ensure connector connections are fully seated and locked
    • Verify the certification markings match the installation area classification
  • Usage Notes:
    • Confirm the specific certification or modification denoted by the “-001” suffix with the supplier documentation before procurement
    • This variant is not universally interchangeable with the base “-00” suffix version in certified installations — the certification documentation must match the hazardous area classification
    • Retain all certification paperwork for compliance audits
