  • Product Overview: The 330930-040-02-00 is a 4.0-meter extension cable within the 3300 XL NSv system with a different armor option than the “-01” variant. The “02” in the armor option position indicates an alternative stainless steel armor configuration, providing a different level or style of mechanical protection suited to specific installation requirements.
Request Quote
Category:

Description

Bently Nevada 330930-040-02-00

  • Technical Specifications:
    • Cable Length: 4.0 meters (13.1 feet)
    • Cable Type: Low-noise coaxial with stainless steel armor (Option 02)
    • Connector Type: ClickLoc miniature coaxial connectors
    • Capacitance: 69.9 pF/m (21.3 pF/ft) typical
    • Operating Temperature: -51°C to +177°C (-60°F to +351°F)
    • Compatibility: 3300 XL NSv proximity probes and 330980 NSv Proximitor sensors
  • Functional Features:
    • Alternative stainless steel armor configuration for specific mechanical protection needs
    • ClickLoc locking connectors for vibration-resistant connections
    • Low-noise coaxial signal transmission
    • Full interchangeability within the 3300 XL NSv system
    • Suitable for demanding industrial environments
  • Application Scenarios:
    • Heavy industrial rotating machinery
    • Compressor and pump monitoring in petrochemical facilities
    • Power plant auxiliary equipment
    • Applications requiring specific armor protection levels
  • Performance Parameters:
    • System sensitivity: 7.87 mV/μm (200 mV/mil) ± 6.5%
    • Linear range: 0.5 to 1.75 mm (20 to 55 mil)
    • Frequency response: 0 to 10 kHz
    • Signal attenuation at 1 kHz: less than 1%
    • Signal attenuation at 10 kHz: less than 5%
  • Material Composition:
    • Low-noise coaxial cable with stainless steel armor (Option 02 configuration)
    • ClickLoc miniature coaxial connectors with gold-plated contacts
    • Industrial-grade outer jacket
  • Structural Features:
    • Stainless steel armored construction (Option 02)
    • Factory-terminated connectors
    • Designed for routing in demanding mechanical environments
  • Working Principle:
    • The cable transmits the high-frequency eddy current excitation signal from the Proximitor to the NSv probe and returns the gap-proportional modulated signal. The armor option provides mechanical protection while maintaining the electrical characteristics required for accurate proximity measurement.
  • Installation Requirements:
    • Route armored cable through conduit or cable tray
    • Maintain minimum bending radius of 45 mm
    • Ground the armor shield at one end only
    • Ensure connector connections are fully seated and locked
    • Verify armor option compatibility with the installation environment
  • Usage Notes:
    • The “-02” armor option differs from the “-01” option in construction style — verify which armor type is specified in the equipment documentation
    • Do not substitute between armor options without confirming mechanical and environmental compatibility
    • This cable is listed in multiple Bently Nevada sensor system configurations as a standard spare part
