Description
ELAU 070-60-020-P1-45-S1-B1
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: 070-60-020-P1-45-S1-B1
- Product Type: AC Servo Motor
- Rated Voltage: 400V AC (via Drive)
- Rated Current: 2.0 Ampere (Nominal)
- Rated Speed: 3000 rpm
- Max Speed: 6000 rpm
- Rated Torque: 0.64 Nm (Nominal)
- Peak Torque: 1.9 Nm
Functional Features:
- High Dynamics: Low rotor inertia allows for extremely fast response times.
- Compact Design: High power density in a small footprint (70mm flange).
- Feedback: Equipped with a high-resolution encoder for precise positioning.
- Thermal Protection: Integrated thermal winding protection.
Application Scenarios:
- Pick and place robots.
- High-speed packaging machines.
- CNC machine tool axes.
- Printing and converting equipment.
Performance Parameters:
- Torque Constant: High torque-to-inertia ratio.
- Control Mode: Supports position, velocity, and torque control modes.
Material Composition:
- Aluminum alloy housing for efficient heat dissipation.
- Neodymium permanent magnet rotor.
- High-grade copper windings.
Structural Features:
- Flange mounting (Square flange).
- Smooth shaft or keyway (depending on specific variant).
- Rear-mounted encoder cover.
Working Principle:
The motor operates on the principle of a synchronous AC motor. The stator windings are energized by a servo drive to create a rotating magnetic field, which interacts with the permanent magnets on the rotor to generate torque. The integrated encoder provides real-time feedback to the drive for closed-loop control.
Installation Requirements:
- Securely mount using the 4-bolt flange pattern.
- Ensure the coupling to the load is rigid to prevent backlash.
- Maintain an ambient temperature within the specified range (typically 0°C to 40°C).
Usage Notes:
- Do not exceed the peak torque rating for extended periods.
- Ensure the servo drive parameters are correctly tuned for this specific motor model.
- Avoid mechanical shock to the encoder at the rear of the motor.
