Description
ELAU ISH070-60017-0-0-00-0-00-00-00
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: ISH070-60017-0-0-00-0-00-00-00
- Product Type: Servo Motor
- Series: ISH (Integrated Servo Motor / Compact)
- Flange Size: 70 mm
- Rated Voltage: 24V DC (Bus voltage via drive) / 400V AC (Drive input)
- Rated Power: Approx. 11W – 12W (Note: ISH series varies, check nameplate)
- Rated Torque: 1.4 Nm to 2.8 Nm (Depending on winding)
- Rated Speed: 6000 rpm (Max)
Functional Features:
- Compactness: Very short axial length for space-saving installation.
- High Torque Density: Delivers high torque relative to its size.
- Advanced Encoder: High-resolution feedback for precise positioning.
- Sealing: Improved sealing (oil seal) on the shaft to prevent ingress of contaminants.
Application Scenarios:
- Robotics (Joint drives).
- Medical technology.
- Semiconductor handling.
- Precision positioning stages.
Performance Parameters:
- Torque: High continuous and peak torque.
- Dynamics: Low inertia for fast acceleration.
Material Composition:
- Aluminum housing.
- High-grade magnetic materials.
Structural Features:
- Smooth shaft.
- Rear connector (Power and Feedback).
- Oil seal on the output shaft.
Working Principle:
The motor converts electrical energy into mechanical rotation. The drive supplies current to the stator windings, creating a magnetic field that drives the permanent magnet rotor. The encoder monitors the rotor position and speed, feeding
