Description
ELAU C200-A2-1-1-1-00
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: C200-A2-1-1-1-00
- Series: C200
- Processor: High-performance DSP/FPGA architecture
- Communication: SERCOS, CANopen, Ethernet
Functional Features:
- Multi-Axis Control: Capable of synchronizing multiple servo drives (up to 99 axes in system).
- High Precision: Utilizes advanced algorithms for position, velocity, and torque control.
- Integrated PLC: Features a built-in Programmable Logic Controller (PLC) for machine logic.
- Diagnostic Tools: Comprehensive software for monitoring and troubleshooting.
Application Scenarios:
- High-speed packaging machinery (filling, labeling, capping).
- Industrial robotics and handling systems.
- Printing and converting equipment.
Performance Parameters:
- Control Loop: High-frequency current, speed, and position loops.
- Response Time: Fast dynamic response for high-speed applications.
- Bus Cycle: Optimized for real-time SERCOS communication.
Material Composition:
- Robust metal housing for EMI shielding and heat dissipation.
- Industrial-grade electronic components.
Structural Features:
- DIN rail or panel mounting options.
- Multiple interfaces for power, communication, and I/O.
- Status LEDs for operational monitoring.
Working Principle:
The controller receives setpoints from the application software and calculates the necessary trajectories. It sends commands via the SERCOS bus to the drive modules (like the MC-4), which execute the motion. It continuously monitors feedback to correct errors and ensure synchronization.
Installation Requirements:
- Mount in a control cabinet with adequate ventilation.
- Ensure proper grounding of the shielded communication cables.
- Configure the IP address and network settings via the diagnostic software.
Usage Notes:
- Use the ELAU diagnostic software for parameterization.
- Ensure the firmware version is compatible with the connected drives.
- Do not disconnect the SERCOS fiber optic cables while the system is powered.
