Description
ELAU PMC‑2‑11‑08‑000‑00‑00‑00‑00‑0K
Technical Specifications: 32‑bit real time motion control processor, maximum supported servo axes quantity 8, program memory 2 MB, data memory 1 MB, backplane bus interface for PMC‑2 rack, 24 VDC control power supply, IP20 protection rating, hot swap compatible inside PMC‑2 rack, operating ambient temperature range 0 °C to +55 °C, module dimension 145 mm × 90 mm × 32 mm, net weight 0.36 kg.
Functional Features: Real time multi axis interpolation and electronic cam function, high precision electronic gearbox synchronization function, supports IEC 61131‑3 standard programming languages, built‑in fault log storage, full system diagnostic information collection and upload, hot swap support inside PMC‑2 rack, firmware online update capability, user program backup and restore function.
Application Scenarios: Medium scale multi axis synchronous control for packaging machinery, printing converting medium size equipment, textile stand alone production stations, small multi axis robotic automation systems, medium complexity special purpose industrial machinery motion control.
Performance Parameters: Real time motion task cycle minimum 1 ms, maximum stored fault event records 3000, program download speed 800 KB/s, performance derating activates when cabinet internal temperature exceeds 45 °C.
Material Composition: Metal reinforced rack mount housing, multi layer high speed industrial printed circuit board, industrial grade flash and RAM memory chips, gold plated backplane contact pins, flame retardant plastic front panel components.
Structural Characteristics: Horizontal plug‑in PMC‑2 rack module structure, front panel multi color LED status indicator array, 24 VDC control power wiring terminals, data and power supplied through system rack backplane, installed horizontally inside PMC‑2 control rack cabinet.
Working Principle: User compiles motion control application program complying with IEC 61131‑3 standard and downloads program into PMC‑2 CPU module. Internal real time processor executes motion logic, electronic cam and electronic gear calculation. Motion setpoint commands are transmitted to each servo drive through rack backplane bus. Controller collects diagnostic feedback data from drives and motors, processes logic tasks and stores fault event records in internal memory.
Installation Requirements: Insert CPU module into designated main slot inside PMC‑2 system rack and lock front panel retaining latches completely; connect stable 24 VDC control power supply; maintain good ventilation and heat dissipation inside control cabinet; ensure backplane pins keep clean and free of dust contamination.
Usage Notes: Verify firmware version compatibility with all connected servo drives and I/O modules; do not extract module while 24 VDC control power supply is energized; back up complete user program before firmware update operation; avoid operation in environment with conductive dust and corrosive gas; inspect rack backplane contact condition regularly under high vibration operating environment.
