ELAU C200-10-1-1-1-00
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: C200-10-1-1-1-00
- Product Type: Motion Controller / PLC
- Axis Control: Supports multi-axis control (typically up to 8 axes depending on configuration).
- Processor: High-performance industrial processor.
- Communication: EtherCAT, CANopen, Modbus TCP.
- Supply Voltage: 24V DC.
Functional Features:
- Multi-Tasking: Capable of handling motion control and logic tasks simultaneously.
- Programming: Supports IEC 61131-3 standard programming languages (Structured Text, Ladder Diagram).
- Synchronization: High-precision synchronization of multiple axes via EtherCAT.
- Integrated I/O: Onboard digital I/O for direct sensor/actuator connection.
Application Scenarios:
- Packaging machinery (filling, sealing, labeling).
- Food and beverage processing lines.
- Pharmaceutical automation.
- Robotics and material handling.
Performance Parameters:
- Cycle Time: Fast logic execution and motion interpolation.
- Precision: High-precision trajectory planning (linear and circular interpolation).
Material Composition:
- Robust industrial plastic/metal housing.
- Gold-plated contact connectors.
Structural Features:
- DIN rail mountable.
- Removable terminal blocks for wiring.
- Status LEDs for diagnostics.
Working Principle:
The controller executes user-written programs to calculate motion profiles (position, velocity, acceleration). It sends these setpoints via a real-time fieldbus (like EtherCAT) to the servo drives, which then power the motors. Simultaneously, it processes logic inputs to manage the machine’s sequence of operations.
Installation Requirements:
- Mount on a standard 35mm DIN rail.
- Ensure 24V DC power supply is stable and filtered.
- Use shielded cables for fieldbus connections.
Usage Notes:
- Configure the network settings (IP address, Node ID) before commissioning.
- Ensure the firmware version matches the application requirements.
- Verify the total current consumption of connected I/O modules.
