Description
ELAU SH070‑60010‑0‑0‑00‑00‑00‑00‑00
Technical Specifications Flange Dimension: 70 mm square mounting‑flange Rated Speed: 6000 rpm Rated Torque: 1.0 Nm Rated Voltage: 400 V AC class Encoder Type: Hiperface multi‑turn absolute‑encoder Built‑in Brake: None Shaft Configuration: Flat‑key output‑shaft Connector Type: 90‑degree rotatable circular power‑and‑feedback‑connectors Protection Class: IP65 Operating Ambient Temperature:‑20 °C to +40 °C Storage Temperature:‑25 °C to +70 °C Cooling Method: Natural convection cooling Mounting Type: Flange‑face IM B5 mounting
Functional Features Hiperface multi‑turn absolute‑encoder outputs complete‑rotor‑absolute‑position‑data immediately after‑power‑on, eliminates homing‑procedure‑requirement‑at‑machine‑start‑up‑stage. Embedded electronic‑motor‑nameplate enables paired‑MC‑4‑servo‑drive‑to‑read‑full‑motor‑parameter‑dataset‑automatically. 90‑degree‑rotatable‑circular‑connectors‑support‑flexible‑cable‑outlet‑direction‑adjustment‑for‑compact‑machine‑internal‑wiring‑layout‑optimization. Stator‑winding‑applies‑F‑grade‑insulation‑system‑to‑guarantee‑stable‑thermal‑performance‑under‑frequent‑high‑cycle‑start‑stop‑operations. IP65‑rated‑housing‑blocks‑dust‑and‑oil‑mist‑intrusion‑from‑industrial‑equipment‑internal‑environment. Brake‑free‑mechanical‑structure‑maintains‑compact‑overall‑axial‑dimension‑of‑motor‑body. Internal‑NTC‑temperature‑sensor‑continuously‑feeds‑stator‑winding‑temperature‑signal‑back‑to‑matched‑servo‑drive‑for‑over‑heat‑protection‑function.
Application Scenarios High‑speed‑light‑duty‑horizontal‑positioning‑axes‑of‑packaging‑machinery; label‑feeding‑and‑registration‑mechanisms; small‑size‑rotary‑indexing‑stations; auxiliary‑motion‑axes‑of‑printing‑and‑converting‑equipment.
Performance Parameters Steady‑state‑speed‑control‑accuracy‑reaches‑±0.01 %. Short‑term‑overload‑capability‑achieves‑250 %‑of‑rated‑torque‑value. Multi‑turn‑absolute‑position‑data‑keeps‑retention‑state‑without‑external‑auxiliary‑power‑supply‑circuit. Low‑rotor‑moment‑of‑inertia‑realizes‑fast‑acceleration‑and‑deceleration‑dynamic‑response‑performance. No‑mechanical‑shaft‑locking‑effect‑appears‑after‑equipment‑power‑supply‑disconnection‑event.
Material Composition Die‑cast‑aluminum‑alloy‑motor‑housing, silicon‑steel‑laminated‑stator‑core, neodymium‑iron‑boron‑high‑energy‑permanent‑magnet‑rotor‑assembly, Hiperface‑multi‑turn‑absolute‑encoder‑module, fluorine‑rubber‑sealing‑gaskets, alloy‑steel‑flat‑key‑output‑shaft, metal‑rotatable‑circular‑connector‑assemblies,‑built‑in‑NTC‑temperature‑sensing‑components.
Structural Characteristics 70‑mm‑square‑mounting‑flange‑equipped‑with‑flat‑key‑machined‑output‑shaft. Rear‑end‑position‑installs‑two‑independent‑90‑degree‑rotatable‑circular‑connectors‑separating‑power‑circuit‑and‑encoder‑feedback‑circuit‑completely. No‑internal‑brake‑assembly‑arranged‑inside‑motor‑cavity‑so‑overall‑axial‑length‑maintains‑compact‑dimension‑specification. Metal‑housing‑nameplate‑permanently‑prints‑full‑part‑number‑SH070‑60010‑0‑0‑00‑00‑00‑00‑00. NTC‑temperature‑sensing‑elements‑attach‑tightly‑onto‑stator‑winding‑surface‑area‑for‑accurate‑temperature‑sampling‑work.
Working Principle Paired‑MC‑4‑servo‑drive‑outputs‑three‑phase‑variable‑frequency‑alternating‑current‑into‑motor‑stator‑windings‑and‑generates‑rotating‑magnetic‑field‑to‑drive‑permanent‑magnet‑rotor‑assembly‑to‑rotate‑at‑target‑speed. Rear‑mounted‑Hiperface‑absolute‑encoder‑continuously‑collects‑rotor‑angular‑position‑and‑rotational‑speed‑signals‑and‑transmits‑feedback‑data‑frames‑back‑to‑servo‑drive‑unit‑for‑current‑speed‑position‑three‑loop‑closed‑loop‑calculation‑processing. Built‑in‑NTC‑sensor‑samples‑real‑time‑stator‑winding‑temperature‑value‑and‑delivers‑temperature‑information‑to‑upper‑level‑servo‑drive‑hardware. Without‑internal‑brake‑components‑inside‑motor‑cavity,‑motor‑output‑shaft‑maintains‑free‑rotation‑status‑once‑main‑power‑supply‑gets‑disconnected.
Installation Requirements Tighten‑flange‑mounting‑screws‑strictly‑follow‑torque‑parameter‑values‑printed‑on‑motor‑metal‑nameplate‑surface. Complete‑high‑precision‑coaxial‑alignment‑between‑motor‑output‑shaft‑and‑load‑coupling‑assembly‑component. Deploy‑fully‑shielded‑motor‑power‑cables‑and‑shielded‑Hiperface‑encoder‑feedback‑cables,‑lock‑circular‑connectors‑completely‑after‑cable‑insertion‑operation‑finishes. Physically‑separate‑low‑signal‑encoder‑wiring‑routes‑away‑from‑high‑voltage‑power‑cable‑routing‑paths. Ensure‑reliable‑protective‑earth‑connection‑between‑motor‑housing‑and‑cabinet‑ground‑busbar‑system. External‑mechanical‑brake‑assembly‑must‑be‑configured‑when‑this‑brake‑free‑motor‑is‑applied‑for‑vertical‑load‑mechanical‑axes‑application‑scenarios.
