Description
ELAU SM100-30-080-P0-45-M1-B1
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: SM100-30-080-P0-45-M1-B1
- Series: SM-100
- Flange Size: 100 mm
- Rated Speed: 3000 RPM
- Encoder: P0 (Standard encoder)
- Feedback Type: M1 (Standard incremental encoder)
- Brake: B1 (Integrated electromagnetic holding brake)
- Protection Class: IP54 or higher
- Dimensions: 69mm × 310mm × 260mm
- Weight: 3.1 kg
- Origin: Germany
Functional Features:
- High Torque Output: Designed for applications requiring significant continuous torque at moderate speeds
- Integrated Holding Brake: B1 brake provides secure load retention during power-off conditions
- Modular Design: Compatible with ELAU PacDrive intelligent servo module system for plug-and-play integration
- Standard Encoder Feedback: P0/M1 configuration provides reliable position feedback for standard precision applications
- Wide Voltage Compatibility: Operating voltage range of 380V to 480V (±10%), with 24V DC control support
- Frequency Range: 48Hz to 62Hz
Application Scenarios:
- Vertical lifting and lowering axes in material handling systems
- Packaging machinery requiring precise positioning (cartoning, case packing)
- Printing machinery (roller drive control)
- Textile machinery (tension, speed, and position control)
- CNC machine tool axes
- Automated storage and retrieval systems
Performance Parameters:
- Power Range: 120W to 520W
- Rated Speed: 3000 RPM (maximum 4500 RPM for some configurations)
- Stall Torque: 8.0 Nm (based on SH-100/30 080 variant data)
- Peak Torque: 10.0 Nm (based on SH-100/30 080 variant data)
- Control Modes: Position, velocity, and torque control
- Communication: RS-232, RS-485, CAN interfaces supported
Material Composition:
- Industrial-grade aluminum housing
- NdFeB permanent magnets
- High-quality copper windings
- Precision steel shaft with standard keyway option
Structural Features:
- 100mm standard flange mounting interface
- Integrated electromagnetic brake at the rear
- Standard flange mounting (S1 single shaft output)
- Sealed connectors for industrial environment protection
- Compact modular design for reduced cabinet space
Working Principle:
The motor operates as a three-phase AC synchronous servo. The drive controls the stator current to create a rotating magnetic field that drives the permanent magnet rotor. The encoder provides continuous position feedback for closed-loop control. The B1 holding brake is spring-applied and electrically released — it engages automatically when power is removed to hold the load in position.
Installation Requirements:
- Mount on a rigid, flat surface using the standard flange interface
- Connect the brake control wires to the correct drive outputs
- Verify the motor rated voltage matches the power supply (380V–480V)
- Ensure adequate ventilation around the motor for heat dissipation
- Check the axial and radial load limits in the technical manual
Usage Notes:
- The holding brake (B1) is for static load retention only — never use it for dynamic braking
- Verify the brake release voltage matches the drive output before commissioning
- Monitor motor temperature during continuous operation, especially in high-ambient-temperature environments
- Ensure the drive is configured for the P0/M1 encoder type
- Periodically inspect the brake for wear if engaged frequently
