Description
ELAU SM10040050P145S
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: SM10040050P145S
- Series: SM100
- Flange Size: 100 mm
- Rated Speed: 4000 RPM
Functional Features:
- High Power Density: Delivers high torque in a compact package.
- Integrated Feedback: Equipped with a high-resolution encoder.
- Robust Construction: Designed for harsh industrial environments.
- Single Cable Technology: Simplifies installation and reduces wiring errors.
Application Scenarios:
- High-speed packaging machinery.
- Robotics and handling systems.
- Printing and converting equipment.
Performance Parameters:
- Rated Torque: 5.0 Nm.
- Control Modes: Position, Velocity, and Torque control.
- Efficiency: High energy efficiency due to permanent magnet design.
Material Composition:
- Housing: Industrial-grade aluminum.
- Magnets: NdFeB permanent magnets.
Structural Features:
- Compact flange mounting design.
- IP65/IP67 rated connectors.
- Self-cooling design for continuous operation.
Working Principle:
The motor operates as a synchronous AC servo motor. The drive supplies three-phase current to the stator windings, creating a rotating magnetic field that interacts with the permanent magnets on the rotor. The integrated encoder provides real-time position feedback.
Installation Requirements:
- Mount securely on a rigid surface using the standard flange.
- Ensure proper alignment of the shaft to avoid mechanical stress.
- Connect the power and feedback cables using shielded connectors.
Usage Notes:
- Verify the voltage rating matches the connected drive.
- Do not exceed the permissible radial and axial loads on the shaft.
- Ensure adequate ventilation for heat dissipation.
