ELAU SR-058-60-005-P0-21-M1-B1-T
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: SR-058-60-005-P0-21-M1-B1-T
- Series: SR-058
- Flange Size: 58 mm
- Brake: Integrated Holding Brake (B1)
Functional Features:
- Compact Design: Small footprint suitable for tight spaces.
- High Torque Density: Delivers significant torque relative to its size.
- Integrated Brake: The “B1” suffix indicates a holding brake for vertical axes.
- Thermal Protection: “T” suffix indicates thermal winding protection.
Application Scenarios:
- Small robotics and automation.
- Medical device manufacturing.
- Precision assembly equipment.
Performance Parameters:
- Rated Speed: 6000 RPM (indicated by ’60’).
- Torque: Optimized for high-speed, low-inertia applications.
- Voltage: Low voltage DC bus compatible.
Material Composition:
- High-grade aluminum housing.
- Neodymium Iron Boron (NdFeB) magnets.
Structural Features:
- Flange mounting.
- IP65 protection (depending on specific assembly).
- Single cable connection option.
Working Principle:
Operates as a synchronous AC servo motor. The stator windings generate a rotating magnetic field that interacts with the permanent magnet rotor. The integrated brake engages when power is removed to hold the load.
Installation Requirements:
- Ensure the flange is clean and flat before mounting.
- Connect the brake wires to the appropriate drive output.
- Verify the thermal protection circuit is connected.
Usage Notes:
- Do not use the holding brake for dynamic stopping.
- Monitor the temperature during continuous operation.
- Ensure the shaft load does not exceed the permissible limits.
