Emerson 1C31181G01
Technical Specifications:
- Brand: Emerson
- Model Number: 1C31181G01
- Product Type: 2-Port Fiber Optic Converter Card
- System Platform: Emerson Ovation DCS
- Input Voltage: 24 VDC
- Output Voltage: 5 VDC
- Communication Interface: RS485
- Operating Temperature: –40°C to +85°C
- Installation Type: DIN rail mount
- Application: Ovation DCS system integration and process control
- Standards: CE, FM
Functional Features:
- Fiber Optic Communication: Provides optical communication links between local and remote I/O nodes in the Ovation remote I/O subsystem
- 2-Port Configuration: Supports connection to two remote nodes via fiber optic cables
- Remote I/O Integration: Part of the Ovation remote I/O architecture, enabling distributed I/O deployment
- High Reliability: Designed for continuous industrial operation with robust signal integrity
- Hot-Swap Capable: Supports online insertion and removal within the Ovation I/O subsystem
Application Scenarios:
- Power Plants: Ovation DCS remote I/O communication in utility power generation
- Chemical Processing: Distributed I/O deployment across large process areas
- Oil and Gas: Remote wellhead and pipeline monitoring systems
- Water Treatment: Distributed monitoring across geographically spread facilities
Material Composition:
- Industrial-grade electronic components
- Fiber optic transceiver modules
- Multi-layer PCB
- Modular housing
Structural Features:
- Ovation DCS standard module form factor
- 2 fiber optic ports for remote node connection
- DIN rail or rack mounting capability
- Status indicator LEDs (Power, Communication, Error)
Working Principle:
The 1C31181G01 converts electrical signals from the Ovation I/O bus into optical signals for transmission over fiber optic cables to remote I/O nodes. It receives optical signals from remote nodes and converts them back to electrical signals for processing by the local controller. This enables reliable, noise-immune communication over extended distances between the controller and distributed I/O equipment.
Installation Requirements:
- Install in the Ovation remote I/O base (1C31206G01 for local, 1C31205G01 for remote)
- Connect fiber optic cables to the two ports
- Ensure proper fiber optic cable routing and bend radius
- Verify compatibility with the Ovation system version
Usage Precautions:
- Handle fiber optic connectors with care to avoid contamination
- Verify fiber optic cable integrity before commissioning
- Ensure proper grounding of the module and rack
- Follow Ovation DCS installation procedures for module insertion sequence
