Product Introduction:
The KJ2201X1-HA1 is a removable terminal block (RTB) designed as a field-wiring interface for Emerson DeltaV I/O modules. It provides a secure, organized connection point between field cables and the I/O card, enabling fast module replacement without disturbing field wiring. The -HA1 variant features robust terminal clamping suitable for standard industrial wire gauges.

Request Quote
Category:

Description

Emerson KJ2201X1-HA1

Technical Specifications:

  • Brand: Emerson (DeltaV)
  • Product Type: Removable Terminal Block (RTB)
  • Power Requirements: None (passive component)
  • Signal I/O Types: Supports analog, discrete, or pulse signals as determined by the mated I/O module
  • Termination Method: Removable block with secure terminal clamping
  • Typical Wire Range: Approximately 0.5–2.5 mm² (20–14 AWG)
  • Input Voltage Compatibility: 30 VDC
  • Maximum Current per Channel: 30 mA
  • Power Consumption: Less than 1W
  • Weight: Approximately 0.18 kg
  • Communication Protocols: RS-485 and Modbus (when paired with compatible modules)

Functional Features:

  • Removable Design: Allows I/O modules to be swapped without disconnecting field wires, significantly reducing maintenance time during turnarounds
  • Clear Channel Identification: Marking areas on the terminal block support fast identification and reduce wiring errors during factory acceptance testing and site acceptance testing
  • Passive and Reliable: No active electronics or firmware required; provides a solid mechanical connection
  • Multi-Signal Compatibility: Works with analog, discrete, and pulse signal types depending on the paired I/O card
  • Scalability: Additional terminal blocks can be added as system I/O expands

Application Scenarios:

  • Refining and petrochemical process control (AI/AO/DI/DO loop termination)
  • Power generation control systems
  • Water and wastewater treatment plants
  • Life sciences and food and beverage manufacturing
  • Pulp and paper mills
  • Mining and metals processing

Performance Parameters:

  • Signal Types: Analog (4–20 mA, 0–10 V), digital (switching, pulse)
  • Wire Gauge Range: 0.5–2.5 mm² (20–14 AWG)
  • Current Rating: 30 mA per channel
  • Voltage Rating: 30 VDC

Material Composition:

  • Industrial-grade housing resistant to vibration, dust, and temperature variations
  • Tin-plated copper alloy contact terminals
  • Screw-type clamping mechanism for field conductors
  • Flame-retardant insulating material

Structural Features:

  • Compact removable block that latches onto compatible DeltaV I/O carriers
  • Clearly labeled terminal positions for each channel
  • Tool-assisted wiring terminals
  • Keyed design to prevent mismatching with incompatible I/O cards

Working Principle:
The terminal block serves as a passive mechanical interface between field wiring and the I/O module. Field cables are terminated on the RTB using screw clamps. When the RTB is latched onto the I/O carrier, spring-loaded contacts establish electrical connections between the field wires and the I/O module circuitry. Removing the I/O module leaves the field wiring intact on the RTB.

Installation Requirements:

  • Latch the terminal block onto the compatible DeltaV I/O carrier baseplate
  • Strip field wires to the appropriate length for the terminal clamp
  • Use tool-assisted tightening to ensure secure connections
  • Verify wire gauge falls within the 0.5–2.5 mm² range
  • Install inside a control cabinet or junction box within the DeltaV system

Usage Precautions:

  • Always de-energize field circuits before wiring or rewiring
  • Verify correct channel-to-terminal mapping before energizing
  • Do not overtighten terminal screws to avoid damaging the clamping mechanism
  • Inspect terminals periodically for corrosion or loose connections
  • Ensure the RTB is fully seated and latched before applying power to the I/O module
