Description
Foxboro FBM08 DM400YJ
Technical Specifications
- Module Type: FBM08 DM400YJ
- Bus Interface: Foxboro Module Fieldbus
- Communication Protocol: Modbus
- Mounting: 200 Series baseplate
Functional Features
- Native Compatibility: Mounts directly on 200 Series baseplates and communicates on the Foxboro Module Fieldbus to the controller.
- Hot-Swappable Maintenance: Supports online replacement without taking down the entire node, minimizing process interruption.
- Redundancy-Ready Architecture: Designed for use in redundant I/A nodes to maintain availability during faults.
- Integrated Diagnostics: Features status LEDs and health reporting to simplify troubleshooting and routine checks.
Application Scenarios
Deployed across process industries including oil and gas, refining, petrochemicals, power generation, and water treatment where Foxboro I/A Series architectures are standard.
Performance Parameters
- Operating Temperature: 0℃ to 60℃
- Ingress Protection: IP20
- Power Requirements: Backplane powered, 24 VDC nominal via 200 Series baseplate
Material Composition
Features conformal-coated electronics and a compact, single-wide form factor designed to fit dense industrial control cabinets.
Structural Characteristics
Standard 200 Series FBM form factor with typical module weight of approximately 0.4 kg. Field terminations are handled via matching terminal assemblies (TAs).
Working Principle
Acquires field signals through the designated terminal assembly, processes the data, and communicates with the I/A Series controller via the backplane fieldbus.
Installation Requirements
Install on a Foxboro 200 Series baseplate in a clean, ventilated enclosure. Allow front access for hot-swap operations and maintain low-impedance protective earth for noise immunity.
Usage Precautions
Land field signals on the designated terminal assembly corresponding to the FBM08. Ensure proper cabinet grounding and ventilation before energizing.
