Foxboro FBM217 P0914TR
Technical Specifications
- Input Type: Discrete / Contact Input
- Input Channels: 32 isolated channels
- Communication Protocol: Redundant 2 Mbps Module Fieldbus
- Hardware Code: P0914TR
Key Features
- Ultra-High Density: Delivers 32 channels in a single module, maximizing cabinet space and backplane slot utilization.
- Reliable Signal Acquisition: Designed for critical digital signal acquisition, ensuring absolute accuracy for interlocks and status feedback.
- Hot-Swappable Maintenance: Supports safe online replacement to minimize unplanned downtime.
- Integrated Diagnostics: Features status LEDs and health reporting for simplified巡检 and troubleshooting.
Application Scenarios
Widely used in oil and gas, refining, and power generation for acquiring valve limit switches, pump run statuses, safety interlock signals, and discrete equipment states.
Performance Parameters
- Operating Temperature: 0°C to 60°C
- Storage Temperature: -40°C to 85°C
- Power Supply: 24 VDC via backplane
Material Composition
Constructed with a robust industrial-grade housing and conformal-coated PCBs to adapt to high-dust and high-humidity environments.
Structural Characteristics
Standard 200 Series FBM single-width form factor weighing approximately 0.4 kg. Connects to field wiring via a dedicated Terminal Assembly and supports cabinet or DIN rail mounting.
Operating Principle
Receives dry contact or voltage signals from the field via the terminal assembly. The signals are optically isolated, conditioned, and converted to digital states, which are periodically updated to the controller via the Module Fieldbus.
Installation Requirements
Mount on a Foxboro 200 Series baseplate. Ensure the control cabinet is well-ventilated and maintains a low-impedance protective ground for noise immunity.
Usage Precautions
Verify that the discrete signal voltage level matches the module specification. Utilize the hot-swap feature to avoid node power-down, but always adhere to standard ESD protocols during handling.
