Description
Foxboro FBM219 P0916RH
Technical Specifications
- Input Type: Voltage Monitor (24 channels)
- Output Type: Discrete Output (8 channels)
- Communication Protocol: Redundant 2 Mbps Module Fieldbus
- Hardware Code: P0916RH
Key Features
- Mixed I/O Design: Integrates voltage monitoring and discrete control in one module, saving cabinet space.
- Comprehensive Status Monitoring: 24 voltage monitor channels for detailed equipment health assessment.
- Reliable Discrete Control: 8 discrete output channels for actuator and indicator control.
- Integrated Diagnostics: Provides channel-level diagnostics for both input and output functions.
Application Scenarios
Ideal for motor control centers, switchgear monitoring, and utility systems where simultaneous voltage monitoring and discrete control are required.
Performance Parameters
- Operating Temperature: 0°C to 60°C
- Storage Temperature: -40°C to 85°C
- Power Supply: 24 VDC via backplane
Material Composition
Constructed with industrial-grade, flame-retardant materials and conformal-coated electronics for long-term reliability.
Structural Characteristics
Standard 200 Series FBM single-width form factor. Interfaces with the backplane via precision connectors and connects to field devices through a matched Terminal Assembly.
Operating Principle
Monitors 24 voltage inputs for equipment status and converts them to digital data. Simultaneously, it receives discrete control commands from the controller
