Foxboro FBM237RH914XS
Foxboro FBM237RH914XS - Image 2

Foxboro FBM237RH914XS

Product Introduction
The Foxboro FBM237RH914XS is a redundant assembly consisting of an FBM237 analog input module paired with RH914XS redundancy hardware. This configuration provides fault-tolerant, high-precision analog measurement for critical process variables, ensuring continuous operation even in the event of a module failure.

Request Quote
Category:

Description

Foxboro FBM237RH914XS

Technical Specifications

  • Product Type: Redundant 8-Channel Analog Input Assembly.
  • Base Module: FBM237 (Redundant 8-Channel 0-20mA Input).
  • Redundancy Hardware: RH914XS Adapter.
  • Signal Type: 0-20 mA (or 4-20 mA with appropriate termination).

Functional Features

  • Seamless Failover: Automatic, bumpless transfer to the secondary module upon primary failure.
  • Continuous Synchronization: Both modules process input signals in parallel, with the controller validating data integrity.
  • Hot-Swap Maintenance: Either module can be replaced without interrupting the process or losing measurement data.
  • High Accuracy: Maintains ±0.1% accuracy in redundant mode.

Application Scenarios
Mandatory for safety-critical measurements, custody transfer, and any analog loop where loss of signal could result in production loss, safety hazards, or environmental incidents.

Performance Parameters

  • Failover Time: Bumpless, <100ms transition.
  • Data Consistency: Bit-exact synchronization between primary and secondary.
  • Channels: 8 fully redundant analog input channels.
  • Resolution: 16-bit A/D conversion.

Material Composition
Combines the FBM237’s industrial-grade analog front-end with the RH914XS redundancy adapter featuring high-reliability relays and isolation circuits. All components are rated for continuous industrial duty.

Structural Characteristics
Occupies two adjacent module positions on the baseplate (FBM + Redundancy Adapter). Front panel LEDs indicate primary/secondary status, sync health, and channel activity.

Working Principle
Both modules independently sample and convert the analog input signals. The redundant control software compares the data from both modules and uses a voting algorithm to determine the valid process value, rejecting any corrupted data from a failing module.

Installation Requirements
Install the FBM237 and RH914XS in adjacent slots as specified by the baseplate documentation. Connect the redundancy sync cable if required. Ensure both modules have identical firmware versions.

Usage Precautions

  • Never remove both modules simultaneously.
  • Monitor redundancy status in system diagnostics; address sync loss immediately.
  • Test failover during scheduled maintenance to verify redundancy integrity.
  • Use shielded twisted-pair wiring for analog signals to prevent noise-induced discrepancies.
