Foxboro FBM242 RH916TA

Foxboro FBM242 RH916TA

Product Introduction
The Foxboro FBM242 RH916TA represents a Fieldbus Module 242 (FBM242) and its associated Termination Assembly (TA). The FBM242 is a discrete output module, and the RH916TA provides the physical wiring interface, relay isolation, and signal conditioning required to safely drive field devices like solenoid valves, motor starters, and indicator lights.

Request Quote
Category:

Description

Foxboro FBM242 RH916TA

Technical Specifications

  • Module Type: FBM242 Discrete Output.
  • Termination: RH916TA Relay/Switching Assembly.
  • Output Type: Relay contacts or solid-state switching (depending on TA configuration).
  • Bus Interface: 2 Mbps Redundant Fieldbus.

Functional Features

  • Safe Switching: Provides galvanic isolation between the low-voltage DCS logic and high-power field loads.
  • High Current Capacity: Relay outputs typically rated for 2A to 5A per channel, suitable for driving inductive loads.
  • Status Feedback: Includes LEDs to indicate output state and relay energization.
  • Modular Design: Allows the electronic FBM to be replaced without disturbing the high-current field wiring connected to the TA.

Application Scenarios
Essential for controlling final control elements, motor control centers (MCCs), and alarm beacons in process automation and manufacturing environments.

Performance Parameters

  • Contact Rating: Typically 250 VAC / 30 VDC at 2A.
  • Switching Life: High mechanical and electrical endurance for relays.
  • Isolation: 1500 VAC channel-to-bus isolation.

Material Composition
FBM: Industrial PCB with conformal coating. TA: Heavy-duty terminal blocks, industrial relays, and flame-retardant housing.

Structural Characteristics
The FBM242 is a standard compact module. The RH916TA is a larger, DIN-rail mountable block with screw terminals for field wiring and a ribbon cable or backplane connector to the FBM.

Working Principle
The FBM receives digital commands from the controller and activates internal optocouplers. These drive the relay coils in the RH916TA, which close or open high-power contacts to control external field devices.

Installation Requirements
Mount the FBM on a baseplate and the TA adjacent to it. Connect the interconnecting cable securely. Wire field loads according to the TA schematic, ensuring proper polarity and load ratings.

Usage Precautions
Never exceed the relay contact ratings. Use snubber circuits for highly inductive loads to prevent contact arcing. Ensure the TA is properly grounded for safety.
