Description
Foxboro P0926KQ
Technical Specifications
- Processor: 32-bit RISC processor.
- Instruction Execution: 0.1 µs/boolean, 0.5 µs/floating-point.
- Memory: 8MB program memory, 4MB data memory.
- Communication: Ethernet 10/100BaseTX, ControlNet, RS-232.
Functional Features
- Massive I/O Support: Accommodates expansion of up to 128 FBM modules.
- Multi-Protocol Support: Compatible with Modbus TCP/IP and Ethernet/IP.
- Seamless Fault Tolerance: Dual-module parallel architecture ensures bumpless switching.
- Real-Time Monitoring: Continuously acquires process variables and handles alarms.
Application Scenarios
Widely deployed in automation control systems of large-scale chemical plants, oil refineries, and power generation facilities.
Performance Parameters
- Power Supply: 24VDC, 10W consumption.
- Environmental Adaptability: G3-class harsh environment compliant.
- Protection Rating: IP20.
Material Composition
Die-cast aluminum enclosure with triple-coated internal PCBs ensures long-term reliability.
Structural Characteristics
- Dimensions: 140mm × 165mm × 45mm.
- Weight: 0.6kg.
- Mounting: Standard rack installation.
Working Principle
Collects field data via a high-speed bus, executes logic and regulation algorithms, dispatches control commands to actuators, and communicates with supervisory systems over Ethernet.
Installation Requirements
- Ensure proper rack grounding.
- Avoid direct sunlight and high-temperature heat sources.
- Secure all wiring connections to prevent loosening.
Usage Precautions
- Strictly prohibit hot-plugging.
- Clean control cabinet filters regularly for optimal cooling.
- Record alarm codes immediately during faults for efficient troubleshooting.
