Foxboro PM900HU
Technical Specifications
- Processor: 32-bit Industrial-grade RISC Processor
- Instruction Speed: 0.1 µs/boolean instruction, 0.5 µs/floating-point instruction
- Memory: 8MB Program Memory, 4MB Data Memory
- Communication Interfaces: Ethernet 10/100BaseTX, ControlNet, RS-232
Functional Features
- High-Speed Processing: Capable of executing complex PID, logic, timing, and sequential control operations with microsecond-level precision.
- Multi-Protocol Communication: Supports seamless integration with Foxboro Evo control networks and upper-level monitoring software like Foxboro InTouch and Wonderware System Platform.
- Robust Data Integrity: Utilizes bit-by-bit matching technology to verify data consistency and prevent erroneous information transmission.
- Flexible Expansion: Supports up to 32 FBM modules natively, expandable to 128 FBMs via FEM100 Fieldbus Expansion Modules.
Application Scenarios
Ideal for large-scale industrial process automation, chemical processing, oil and gas refineries, and power generation plants requiring high-speed data acquisition and real-time control.
Performance Parameters
- Power Supply: 24VDC, 10W power consumption
- Environmental Rating: IP20, G3 harsh environment certified (high dust, strong EMI)
- Operating Temperature: 0℃ to 60℃
- Storage Temperature: -40℃ to 85℃
Material Composition
Housed in a die-cast aluminum enclosure for superior physical protection and electromagnetic shielding. Internal PCBs are conformally coated to withstand harsh industrial atmospheres.
Structural Characteristics
Compact industrial form factor measuring 140mm × 165mm × 45mm, weighing 0.6kg. Features a secure backplane connector for reliable electrical contact and hot-swappable capabilities.
Working Principle
The 32-bit RISC processor continuously executes stored control logic, reading real-time process variables from connected I/O modules, performing high-speed mathematical computations, and outputting precise control signals via redundant fieldbus networks to maintain optimal process conditions.
Installation Requirements
Must be securely mounted in a compatible Foxboro controller chassis. Ensure adequate ventilation to maintain operating temperatures below 60℃. Connect redundant Ethernet and power supplies as per system architecture guidelines.
Precautions for Use
Always back up control logic before replacing the module. Do not insert or remove the module while the backplane is energized unless explicitly rated for hot-swapping. Ensure the operating environment does not exceed G3 severity levels.
