Description
GE DS200RTBAG2A
Technical Specifications
- Product Series: GE DS200 Drive Control Series.
- Revision: G2A.
- Function: Discrete relay outputs and signal routing.
- Isolation: Galvanic isolation between control logic and field outputs.
Functional Features
- Discrete Outputs: Controls external contactors, solenoids, and indicator lights.
- Signal Routing: Distributes control signals from the main processor to field devices.
- Fault Protection: Protects the main control board from field voltage spikes.
Application Scenarios
AC/DC motor drives, industrial process control panels, and auxiliary system automation.
Performance Parameters
- Contact Rating: Rated for standard industrial control currents.
- Switching Speed: Optimized for discrete control applications.
Material Composition
Industrial PCB with electromechanical relays, opto-isolators, and protective snubber circuits.
Structural Characteristics
Standard DS200 board form factor with multi-pin connectors and front-panel status LEDs.
Working Principle
Receives digital commands via the backplane, energizes relay coils through isolation barriers, and switches field circuits to execute control actions.
Installation Requirements
- Install in the designated drive control slot.
- Ensure all output loads are properly fused.
Usage Precautions
- Do not exceed the relay contact current/voltage ratings.
- Verify proper wiring polarity for DC loads.
