Description
GE DS3800HXPD1B1D
Technical Specifications
- Part Number: DS3800HXPD1B1D
- System Compatibility: GE Mark IV Speedtronic
- Product Type: I/O / Interface Board
Functional Features
- Signal Conditioning: Scales and isolates field signals for the processor.
- Field Wiring Interface: Provides terminal connections for turbine sensors.
- Diagnostics: Detects open circuits, short circuits, and out-of-range signals.
Application Scenarios
Turbine temperature, pressure, and speed monitoring; valve actuator control.
Performance Parameters
- Signal Accuracy: High-precision analog measurement.
- Isolation: Channel-to-channel and channel-to-ground isolation.
Material Composition
Precision analog ICs, optical isolators, and industrial-grade PCB.
Structural Characteristics
Standard Mark IV form factor with front-panel terminal blocks or backplane connections.
Working Principle
Field signals are routed through isolation and conditioning circuits, then digitized and transmitted across the backplane to the Mark IV processor.
Installation Requirements
- Wire field devices according to the Mark IV wiring diagram.
- Verify signal types match board configuration.
- Secure all terminal connections properly.
Usage Precautions
- Never apply voltages exceeding the board’s rated input.
- Verify thermocouple polarity and type.
- Observe ESD precautions during handling.
