Description
GE DS3800XTFW1C1C
Technical Specifications
- Product Line: GE Speedtronic Mark IV.
- Part Number: DS3800XTFW1C1C.
- Board Type: Turbine Control / Signal Conditioning Board.
- Suffix: 1C1C (Specific revision and feature set).
Functional Features
- Precision Signal Conditioning: Processes turbine sensor signals with high accuracy.
- Redundancy Compatibility: Designed for redundant safety systems.
- Actuator Interface: Controls and monitors turbine control valves.
- Diagnostics: Comprehensive onboard fault detection and reporting.
Application Scenarios
Critical component in gas and steam turbine control systems for power generation and industrial cogeneration.
Performance Parameters
- Signal Accuracy: High-resolution analog processing.
- Safety Integrity: SIL-rated safety functions.
- Environmental Rating: Withstands turbine enclosure conditions.
Material Composition
Multi-layer PCB with conformal coating, precision analog components, and gold-plated backplane connectors.
Structural Characteristics
Standard Mark IV board with front panel test points, status LEDs, and precision edge connector.
Working Principle
Conditions sensor signals, executes control logic, and interfaces with the Mark IV core processor to manage turbine operation safely and efficiently.
Installation Requirements
Install in designated Mark IV rack slot. Ensure proper alignment and secure mounting.
Usage Precautions
Never hot-swap. Verify exact part number and suffix. Follow all turbine safety and lockout/tagout procedures.
