Description
GE IC693CHS397 Technical Specifications:
- Rack Type: 7-Slot Expansion Rack
- System Compatibility: GE Fanuc Series 90-30
- Slot Count: 7 standard module slots
- Backplane: Passive backplane with 5V DC and 24V DC power buses
Functional Features:
- Space-Saving Design: Smaller footprint than 10-slot racks.
- Modular Expansion: Supports all standard Series 90-30 I/O and communication modules.
- Power Distribution: Reliable backplane power distribution.
Application Scenarios:
- Medium-sized machine control panels.
- Systems with limited panel space.
- Distributed I/O racks with moderate I/O requirements.
Performance Parameters:
- Backplane Current: Rated for specific current capacities.
- Slot Pitch: Standard Series 90-30 module width.
Material Composition & Structural Characteristics:
- Frame: Metal chassis with DIN rail mounting.
- Backplane: Multi-layer PCB with robust edge connectors.
- Grounding: Dedicated grounding stud.
Working Principle: Identical to the CHS391 but with fewer slots. Provides passive backplane connectivity and power distribution for installed modules.
Installation Requirements:
- Mounting: DIN rail or panel mount.
- Power Supply: Size power supply for total module load.
- Grounding: Proper earth ground connection.
Usage Precautions:
- Slot Planning: Optimize module placement for heat dissipation and wiring convenience.
- Connector Care: Avoid damaging backplane pins during module installation.
- Expansion: Verify CPU support for this rack size.
