Kollmorgen DBL2H00060-0R2-110-S40
Technical Specifications
- Series: DBL Synchronous Servomotors
- Output Power: 0.33 kilowatts
- Frame Size: DBL2 series compact frame
- Winding Code: 0R2
- Feedback: Resolver or encoder configuration per model variant
- Protection Class: IP64 rated enclosure
Functional Features
- Neodymium magnets for highly dynamic performance
- Flange dimensions per IEC standard with J6 fit
- Accuracy in accordance with DIN 42955 tolerance class R
- Vibration class N per DIN ISO 2373
- Insulation material class F per DIN 57530
- Shaft end without keyway as standard configuration
- Built-in resolver for position feedback
Application Scenarios
- Precision positioning systems
- Small automated machinery
- Packaging equipment
- Material handling systems
- Industrial automation requiring compact servo motors
Performance Parameters
- 0.33 kilowatt continuous power output
- High dynamic response from neodymium magnet construction
- Smooth low-speed operation for precision tasks
- Reliable feedback signal for closed-loop control
Material Composition and Structure
- Powder-coated aluminum housing for corrosion resistance
- Neodymium iron boron permanent magnets
- Class F insulation materials
- Sealed bearings for maintenance-free operation
- Integrated thermal protection sensors
Working Principle The motor operates as a permanent magnet synchronous machine. Three-phase sinusoidal current from a servo drive creates a rotating magnetic field in the stator windings. This field interacts with neodymium permanent magnets on the rotor, producing continuous electromagnetic torque. The built-in resolver provides absolute rotor position feedback to the drive for electronic commutation and closed-loop speed or position control.
Installation Requirements
- Mount using IEC standard flange with J6 fit tolerance
- Use flexible coupling with misalignment tolerance less than 0.1 millimeters angular and 0.05 millimeters parallel
- Connect to compatible Kollmorgen servo drive with appropriate cable shielding
- Ensure connector sealing in washdown or dusty environments
Operating Precautions
- Do not exceed maximum rated speed under any operating condition
- Use shielded motor cable with maximum 15 meter length without additional filtering
- Monitor coil temperature through integrated thermal sensors
- Verify drive compatibility with motor winding parameters before operation
