Kollmorgen LS2000
Technical Specifications
- Product Series: LS2000 Linear Motor
- Drive Type: Direct-drive linear synchronous motor
- Continuous Force Range: Optimized for high thrust density
- Peak Force: High peak force for rapid acceleration and deceleration
- Maximum Velocity: High-speed linear travel capabilities
- Feedback Resolution: High-resolution linear encoder interface
- Thermal Protection: Integrated thermal sensors for winding protection
- Protection Class: IP65 / IP67 (Depending on specific variant)
- Operating Temperature: Standard industrial range with advanced thermal management
Functional Features
- Zero Backlash: Direct-drive architecture eliminates mechanical transmission errors and wear.
- High Dynamic Response: Extremely low moving mass enables high acceleration and settling times.
- Smooth Motion: Advanced electromagnetic design minimizes force ripple and cogging for ultra-smooth velocity.
- High Power Density: Compact forcer design delivers maximum thrust in a minimal footprint.
- Integrated Thermal Management: Built-in temperature monitoring ensures reliable operation under continuous high-load conditions.
- Flexible Mounting: Modular design allows for easy integration into custom linear stages.
Application Scenarios
- Semiconductor Lithography & Inspection: Wafer scanning and precision stage positioning.
- High-Speed Pick-and-Place: Rapid linear transport in packaging and assembly automation.
- Precision Metrology: Coordinate measuring machines (CMM) and optical inspection systems.
- Laser Processing: High-speed laser cutting, welding, and marking stages.
- Medical Imaging: Smooth, vibration-free linear movement in CT and MRI scanners.
Performance Parameters
- Positioning Accuracy: Sub-micron linear positioning resolution.
- Acceleration: Capable of multi-G acceleration depending on load mass.
- Velocity Ripple: Extremely low force ripple for superior surface finish and edge quality.
- Settling Time: Near-instantaneous settling at target positions.
Material Composition
Features high-energy rare-earth permanent magnets, precision-wound copper coils with high-temperature insulation, and a robust aluminum or stainless steel housing. The linear encoder scale is constructed from glass or steel with high-precision graduation.
Structural Features
- Compact Forcer: Lightweight, low-profile moving coil or magnet design.
- Integrated Encoder: High-resolution linear encoder integrated directly into the motor track.
- Sealed Construction: IP65/IP67 rated options protect against coolant, dust, and debris.
- Standardized Interfaces: Pre-wired cables with industrial-grade connectors for quick installation.
