Description
Kollmorgen S20630VTS
Technical Specifications Series: S200 Servo Drives Rated Output Current: 6 A RMS continuous Peak Output Current: 18 A RMS Power Supply: 120/240 VAC or 20-90 VDC operation Current Loop Bandwidth: Up to 5 kHz Velocity Loop Bandwidth: 800 Hz PWM Switching Frequency: 31.2 kHz Feedback Resolution: 24-bit high-resolution feedback support
Performance Parameters The drive delivers 500 W of continuous output power at 75 VDC bus voltage. The control stage operates with high-speed update rates for rapid current and velocity regulation. The unit supports motors with phase inductance up to 15 mH without instability. Peak current can be sustained for 3 seconds before automatic return to continuous rating.
Functional Characteristics The S20630VTS features intelligent feedback device support with electronic motor nameplate capability, enabling plug-and-play commissioning without manual parameter entry. Standard control modes include torque and velocity control with electronic gearing functionality. The drive supports 18-bit analog reference input and encoder equivalent output. Options are available for indexing or SynqNet-based programmable motion control.
Structural Features Height: 152.4 mm Width: 54.8 mm (AC variant) Depth without Connectors: 132 mm Depth with Connectors: Approximately 180 mm The compact footprint enables high-density mounting in control cabinets. The drive features high-density connectors and optically isolated inputs/outputs for noise immunity.
Installation Requirements Mount the drive vertically on a conductive, grounded surface in a control cabinet. Maintain adequate clearance for airflow and heat dissipation. Connect motor power, feedback, and control cables according to the wiring diagram. Provide external DC bus capacitance of at least 4000 µF for stable low-voltage operation. Ensure connected motors offer minimum 0.2 mH phase inductance.
Operating Considerations The drive meets UL 508C, CE, EN50178, EN61800-C, and Semi F47 standards. A separate Keep Alive power input allows rapid recovery from emergency stop conditions. The drive supports positive locking connectors and full fault protection for immunity to accidental damage. Use factory-manufactured cables for reliable operation.
