Product Introduction
S21260-SRS is a high-performance compact brushless servo drive from the Kollmorgen S200 series (manufactured by Danaher Motion). It delivers first-class servo performance with the highest speed loop bandwidth of 800Hz among fully digital industrial drives. Combined with 24-bit high-resolution feedback and 3–5 kHz current loop bandwidth, it provides smooth motion and fast start-stop actions to optimize machine throughput.

Request Quote
Category:

Description

Kollmorgen S21260-SRS

Technical Specifications

  • Product Series: S200
  • Input Voltage: 120/240 VAC and 20–90 VDC
  • Current Range: 1.5A RMS continuous to 48A RMS peak
  • Feedback Resolution: 24-bit high-resolution
  • Current Loop Bandwidth: 3–5 kHz
  • Speed Loop Bandwidth: 800 Hz
  • Analog Reference Input: Up to 18-bit
  • Dimensions: 28.7mm to 94.6mm (W) × 152.4mm to 213mm (H) × 100.8mm to 192.4mm (D) depending on model
  • Certifications: UL 508C, CE, EN50178, EN61800-3

Functional Features

  • 800Hz Speed Loop Bandwidth: Industry-leading bandwidth providing superior system throughput and simplified tuning.
  • 24-Bit High-Resolution Feedback: Delivers smooth motion and fast start-stop actions.
  • Plug-and-Play Commissioning: Smart feedback with electronic motor nameplate eliminates servo loop tuning in most applications.
  • Standard Control Modes: Torque and speed control as standard.
  • Optional Communication: Factory options for SynqNet motion network or CANopen with pre-settable index.
  • Optional Feedback Interfaces: Comcoder, 1 Vp-p Sin/Cos, EnDat 2.1, and EnDat 2.2 (operating in 2.1 compatible mode).
  • Encoder Compatibility: EnDat interface accommodates single-turn and multi-turn absolute rotary or incremental and absolute linear encoders.

Application Scenarios

  • Semiconductor Manufacturing: Wafer handling and precision positioning stages.
  • Electronics Assembly: High-speed pick-and-place and soldering equipment.
  • Packaging Equipment: High-throughput filling, sealing, and labeling machines.
  • Medical Devices: Precision motion control for imaging and surgical equipment.
  • Woodworking Equipment: CNC routers and precision cutting machines.
  • Robotics: Joint drive and trajectory control for industrial robots.

Performance Parameters

  • Speed Loop Bandwidth: 800 Hz
  • Current Loop Bandwidth: 3–5 kHz
  • Feedback Resolution: 24-bit
  • Peak Current: Up to 48A RMS

Material Composition
Industrial-grade components with advanced circuit design. Compact housing with robust construction for harsh industrial environments.

Structural Features
Compact footprint ranging from 28.7mm to 94.6mm in width, enabling installation in tight spaces. Multiple connector options for power, feedback, and communication.

Working Principle
The drive converts AC or DC input power into precisely controlled three-phase AC output for brushless servo motors. The full-digital control architecture executes current, speed, and position closed-loop algorithms with 800Hz speed loop bandwidth, enabling rapid response to command changes while maintaining smooth motion.

Installation Requirements

  • Install in a control cabinet with adequate ventilation.
  • Ensure proper grounding and cable shielding.
  • Use locking connectors for all power and feedback connections.
  • Verify input voltage matches the drive specification.

Usage Notes

  • The 800Hz speed loop bandwidth eliminates the need for servo loop tuning in most applications when paired with AKM servo motors.
  • Select appropriate feedback interface option card based on the motor encoder type.
  • Monitor drive status through the user interface for fault diagnostics.
  • Ensure adequate cooling space around the drive.
