Kollmorgen SR85201-Y088
Technical Specifications
| Parameter Category | Specific Specification |
|---|---|
| Manufacturer | Kollmorgen (Danaher Motion) |
| Product Family | SERVOSTAR S200 Series (Enhanced) |
| Power Supply | 3-Phase, 230 VAC nominal |
| Input Current | 100+ Amps per phase |
| Input Power | 40+ kVA |
| Output Voltage | 3 x 230 VAC (variable frequency) |
| Output Current | 85.0 Amps RMS continuous per phase |
| Peak Output Current | 170.0 Amps RMS (2 seconds) |
| Output Power | 34 kVA continuous |
| PWM Frequency | 8 kHz |
| Control Modes | Torque, velocity, position |
| Command Interface | ±10V analog, step/direction, encoder following, optional fieldbus |
| Feedback | Resolver, incremental encoder, SFD, absolute encoder |
| I/O | 6 digital inputs, 4 digital outputs, 2 analog outputs |
| Protection | Overcurrent, overvoltage, undervoltage, overtemperature, phase loss, ground fault, stall detection, short circuit |
| Operating Temperature | 0°C to +40°C |
| Storage Temperature | -25°C to +55°C |
| Protection Class | IP20 |
Key Features
- Ultra-High Current Capacity: 85A continuous output with 2:1 peak capability drives very large servo motors up to approximately 22 kW at 230 VAC
- Enhanced Power Stage: Oversized IGBT modules with advanced thermal management for extreme duty cycles
- Comprehensive Feedback Support: Compatible with all feedback technologies including high-resolution absolute encoders
- Expanded I/O and Communication: Enhanced I/O count and optional fieldbus interfaces for complex system integration
- Advanced Protection Suite: Includes short-circuit protection and predictive thermal management
- Rugged Construction: Heavy-duty enclosure and components designed for harsh industrial environments
Application Scenarios
- Very large CNC machines: Drives axis motors in large gantry mills, bridge mills, and heavy-duty machining centers
- Heavy-duty robotics: Powers large industrial robots in automotive body shops and heavy manufacturing
- Metal forming and forging: Controls large servo presses, forging hammers, and extrusion equipment
- Large plastic machinery: Drives clamp and injection systems in very large-tonnage injection molding machines
- Steel and aluminum mills: Controls main drives in rolling mills, continuous casters, and processing lines
- Large test equipment: Powers structural test rigs, fatigue testers, and large dynamometers
- Mining and heavy machinery: Drives conveyors, hoists, and positioning systems in mining operations
- Marine applications: Controls propulsion and positioning equipment in specialized vessels
Performance Parameters The drive extends the S200 series performance to ultra-high power levels. The 800 Hz velocity loop bandwidth is maintained for responsive control. The current loop bandwidth of 3-5 kHz ensures smooth torque delivery at 85A levels. Position loop update rate is 500 microseconds. The drive includes advanced features such as adaptive filtering, vibration suppression, and sophisticated thermal modeling. Current regulation maintains 1% accuracy across the full operating range. The drive supports master-slave configurations for multi-motor applications.
