Description
LAM 810-800081-022
Technical Specifications:
- Brand: LAM
- Model: 810-800081-022
- Product Type: Safety Interlock Module
- System Compatibility: LAM Equipment Safety Systems
Functional Features:
- Hazard Detection: Monitors door switches, gas leaks, over-temperature, and emergency stop buttons.
- Fail-Safe Design: Defaults to a safe state (power off/valves closed) upon any fault detection or power loss.
- Redundant Monitoring: Dual-channel architecture to prevent single-point failures in safety monitoring.
Application Scenarios:
Mandatory component in all LAM tools to comply with international safety standards (CE, UL, SEMI S2/S8) and protect operators from electrical, chemical, and mechanical hazards.
Performance Parameters:
- Response Time: Millisecond-level shutdown activation upon fault detection.
- Safety Integrity: Meets SIL3/PLe safety integrity level requirements.
- Reliability: Exceptionally high MTBF for safety-critical applications.
Material Composition:
Industrial safety-rated relays, high-dielectric components, and flame-retardant PCB materials.
Structural Characteristics:
Distinctive safety-yellow or red housing with clearly labeled interlock inputs and safety status indicators.
Working Principle:
Continuously polls safety sensors and interlock switches. If any safety parameter is violated, the module immediately de-energizes safety relays to isolate power and close gas valves.
Installation Requirements:
Must be installed according to the equipment safety manual. All safety interlock circuits must be wired in series and tested before operation.
Usage Precautions:
Never bypass, jumper, or modify safety interlock circuits. Only qualified safety technicians should perform maintenance or testing on this module. Regular safety audits are mandatory.
